Hardware Installation - 10 -
1-2 Product Specifications
CPU Support for AM3/AM2+/AM2 processors:
AMD Phenom
™
II processor/ AMD Phenom
™
processor/
AMD Athlon
™
II processor/ AMD Athlon
™
processor/
AMD Sempron
™
processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus 2000 MT/s
Chipset NVIDIA
®
GeForce 7025/nForce 630a chipset
Memory 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR2 1066/800/667 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio Realtek ALC883 codec
High Definition Audio
2/4/5.1/7.1-channel
(Note 2)
Support for S/PDIF In/Out
Support for CD In
LAN RTL8201CL chip (10/100 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16
1 x PCI Express x1 slot
2 x PCI slots
Storage Interface NVIDIA
®
GeForce 7025/nForce 630a chipset:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors supporting up to 2 SATA 3Gb/s devices
- Support for SATA RAID 0 and RAID 1
iTE IT8718 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB Integrated in the NVIDIA
®
GeForce 7025/nForce 630a chipset
Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x floppy disk drive connector
1 x IDE connector
2 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x surround/center audio header
1 x CD In connector
1 x S/PDIF In/Out header
2 x USB 2.0/1.1 headers
