Gigabyte GA-M68M-S2 (rev.1) [37/96] Precharge time

- 37 - BIOS Setup

Trfc1 for DIMM3

Options are: 75ns, 105ns, 127.5ns, 195ns, 327.5ns.

Trfc3 for DIMM4

Options are: 75ns, 105ns, 127.5ns, 195ns, 327.5ns.

Write Recovery Time

Options are: Auto (default), 3T~6T.

Precharge Time

Options are: Auto (default), 2T, 3T.

Row Cycle Time

Options are: Auto (default), 11T~26T.

RAS to RAS Delay

Options are: Auto (default), 2T~5T.
