Pin No# Status 8-Port Model
Pin 1 ON Enable broadcast storm rate limiting.
OFF Disable broadcast storm rate limiting.
Pin 2 ON Enable the power alarm.
OFF Disable the power alarm.
LED STATUS INDICATIONS
LED Name Status Condition
P1 Solid green P1 power line has power.
Off P1 power is disconnected or is not being powered.
P2 Solid green P2 power line has power.
Off P2 power is disconnected or is not being powered.
Alarm Solid red Power failure alarm triggered.
Off No power failure alarm.
Copper 1 to N port
Link/Act
Solid green Ethernet link up but no traffic is detected.
Blinking green Ethernet link up and there is traffic detected.
Off Ethernet link down.
Copper 1 to N port
Speed
Solid yellow A 100Mbps connection is detected.
Off No link, or a 10Mbps connection is detected.
SFP 1 to N port
(N=0,1,2)
Link/Act
Solid green SFP port link up.
Off SFP link down.
Additional Information
You can refer to the user manual or visit http://support.dlink.com/ for more support.
Online Support
If there are any issues that are not in the user manual, please visit http://support.dlink.com/ which will direct
you to your appropriate local D-Link support website.
Warranty Information
Visit http://warranty.dlink.com/ to view the D-Link Warranty information.
SAFETY INSTRUCTIONS
The following general safety guidelines are provided to help ensure your own personal safety and protect
your product from potential damage. Remember to consult the product user instructions for more details.
Static electricity can be harmful to electronic components.
Discharge static electricity from your body (i.e. touching grounded bare metal) before touching the product.
Do not attempt to service the product and never disassemble the product. For some products with a user
replaceable battery, please read and follow the instructions in the user manual.
Do not spill food or liquid on your product and never push any objects into the openings of your product.
Do not use this product near water, areas with high humidity, or condensation unless the product is
specifically rated for outdoor application.
Keep the product away from radiators and other heat sources.
Always unplug the product from mains power before cleaning and use a dry lint free cloth only.
