D-Link DGS-1100-10/ME User Manual

TFTP: TFTP (Trivial File Transfer Protocol) is a file transfer protocol that allows you to transfer files to a

remote TFTP server. Specify TFTP Server IPv4 or IPv6 Address, and TFTP File Name for the configuration

file you want to save to / restore from.

Click Backup to save the current log to the TFTP server.

Click Restore after selecting the backup log file you want to restore.

Firmware Backup & Upgrade

Allow for the firmware to be saved, or for an existing firmware file to be uploaded to the Switch. Two methods

can be selected: HTTP or TFTP.

Figure 4.10 – Tool Menu > Firmware Backup and Upgrade

HTTP: Backup or upgrade the firmware to or from your local PC drive.

Click Backup to save the firmware to your disk.

Click Browse to browse your inventory for a saved firmware file.

Click Upgrade after selecting the firmware file you want to use.

TFTP: Backup or upgrade the firmware to or from a remote TFTP server. Specify TFTP Server IPv4 or IPv6

Address and File Name for the configuration file you want to save to / restore from. The maximum Telnet

Server connection is 4.

Click Backup to save the firmware to the TFTP server.

Click Upgrade after selecting the firmware file you want to restore.

CAUTION: Do not disconnect the PC or remove

the power cord from device until the upgrade

completes. The Switch may crash if the firmware

upgrade is incomplete.

Tool Bar > Online Help

The Online Help provides two ways of online support:

Figure 4.11 – Online Help

D-Link Support Site: This will re-direct you to the D-Link website where you can find online resources such

as updated firmware images.

User Guide: This can offer an immediate reference for the feature definition or configuration guide.
