xStack

DGS-3120 Series Managed Switch Hardware Installation Guide

• DEM-331T/R (WDM transceiver, Single-Mode 40km)

• DGS-712 (1G Copper, 1000Base-T, 100m)

• DEM-210 (100Base-FX, Single-Mode 15km)

• DEM-211 (100Base-FX, Multi-mode, 2km)

• DEM-220T/R (100Base-BX, Single-Mode, 20km)

Compliant to following standards:

• IEEE 802.3z compliance

• IEEE 802.3x Flow Control support for Full-Duplex mode.

• Support Auto-negotiation for Full-Duplex/ flow control operations
