English
4
•
Impedance Sensing on Rear Out port
•
Individual PCB Layers for R/L Audio Channel
•
RGB LED
•
Gold Audio Jacks
•
15μ Gold Audio Connector
•
Supports Creative SoundBlaster Cinema5
LAN
1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon
RTL8125AG)
•
Supports Phantom Gaming LAN Soware
- Smart Auto Adjust Bandwidth Control
- Visual User Friendly UI
- Visual Network Usage Statistics
- Optimized Default Setting for Game, Browser, and
Streaming Modes
- User Customized Priority Control
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
1 x Gigabit LAN 10/100/1000 Mb/s (Intel® I219V)
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x Antenna Bracket
•
1 x PS/2 Mouse/Keyboard Port
•
1 x D-Sub Port
•
1 x HDMI Port
•
1 x DisplayPort 1.2
•
1 x Optical SPDIF Out Port
•
1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (ReDriver) (Supports
ESD Protection)
•
1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports
ESD Protection)
•
4 x USB 3.1 Gen1 Ports (Intel® Z390) (Supports ESD
Protection)
