English
25
Z390 Phantom Gaming 6
ATX 12V Power
Connector
(8-pin ATX12V1)
(see p.8, No. 1)
is motherboard
provides an 8-pin ATX
12V power connector. To
use a 4-pin ATX power
supply, please plug it along
Pin 1 and Pin 5.
ATX 12V Power
Connector
(4-pin ATX12V2)
(see p.8, No. 2)
Please connect an ATX
12V power supply to this
connector.
*e power supply plug
ts into this connector in
only one orientation.
underbolt AIC
Connectors
(5-pin TB1)
(see p.8, No. 26)
Please connect a underbolt™
add-in card (AIC) to the
underbolt AIC connector via
the GPIO cable.
*Please install the underbolt™
AIC card to PCIE6 (default
slot).
Serial Port Header
(9-pin COM1)
(see p.8, No. 23)
is COM1 header
supports a serial port
module.
TPM Header
(17-pin TPMS1)
(see p.8, No. 24)
is connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
digital certicates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.
4 1
8 5
1
CCTS#1
RRTS#1
DDSR#1
DDTR#1
RRXD1
GND
TTXD1
DDCD#1
1
RRI#1
1
GN D
SM B_DAT A_MAIN
LA D2
LA D1
GN D
S_ PWRDW N #
SE RIRQ #
GN
D
P CICL K
P CIRS T
#
LA D3
+3 V
LA D0
+3VS B
GN D
FR AM E
SM B_CLK _MAIN
