ASRock Z390 Phantom Gaming-ITX/ac [11/98] English
![ASRock Z390 Phantom Gaming-ITX/ac [11/98] English](/views2/1461808/page11/bgb.png)
4
English
•
Impedance Sensing on Rear Out port
•
Individual PCB Layers for R/L Audio Channel
•
Gold Audio Jacks
•
15μ Gold Audio Connector
•
Supports Creative SoundBlaster Cinema5
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
Giga PHY Intel® I219V
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Wireless
LAN
•
Intel® 802.11ac WiFi Module
•
Supports IEEE 802.11a/b/g/n/ac
•
Supports Dual-Band (2.4/5 GHz)
•
Supports high speed wireless connections up to 1733Mbps
•
2 antennas to support 2 (Transmit) x 2 (Receive) diversity
technology
•
Supports Bluetooth 5.0 + High speed class II
•
Supports MU-MIMO
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x PS/2 Mouse/Keyboard Port
•
1 x HDMI Port
•
1 x DisplayPort 1.2
•
1 x Intel® underbolt
TM
3 (Compatible with USB 3.1 Gen2
and USB-C Display)*
* Supports USB PD 2.0 up to 12V@3A (36W) charging
•
1 x Optical SPDIF Out Port
•
4 x USB 3.1 Gen2 Type-A Ports (10 Gb/s) (Supports ESD
Protection)
•
2 x USB 3.1 Gen1 Ports (Supports ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
1 x Clear CMOS Button
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone (Gold Audio Jacks)
