23
Appendix
Specifications
General
Rated power source ............ 14.4 V DC
(allowable voltage range:
12.0 – 14.4 V DC)
Earthing system................... Negative type
Max. current consumption
................................... 10.0 A
Display unit:
Dimensions (W
✕
H
✕
D):
DIN
Chassis................. 178
✕
50
✕
160 mm
Nose...................... 188
✕
58
✕
34 mm
D
Chassis................. 178
✕
50
✕
165 mm
Nose...................... 170
✕
46
✕
29 mm
Weight .......................... 2.5 kg
Hideaway unit:
Dimensions (W
✕
H
✕
D)
................................... 180
✕
30
✕
140 mm
Weight .......................... 0.7 kg
Navigation
GPS Receiver:
System.......................... L1, C/Acode GPS
SPS (Standard Positioning Service)
Reception system........ 8-channel multi-channel
reception system
Reception frequency ... 1,575.42 MHz
Sensitivity ..................... –130 dbm
Position update frequency
................................... Approx. once per second
GPS aerial:
Aerial ............................ Micro strip flat aerial/right-
handed helical polarization
Aerial cable .................. 5.0 m
Dimensions (W
✕
H
✕
D)
................................... 33
✕
13
✕
36 mm
Weight .......................... 105 g
Display
Screen size/aspect ratio ..... 6.5 inch wide/16:9
(effective display area: 144
✕
76 mm)
Pixels .................................... 336,960 (1,440
✕
234)
Type....................................... TFT active matrix, transmis-
sive type
Colour system...................... NTSC/PAL compatible
Operating temperature range
........................................... –10 – +50
°C
Storage temperature range
........................................... –20 – +80 °C
Angle adjustment................ 50 – 110°
(initial settings: 110°)
Audio
Maximum power output ..... 50 W
✕
4
50 W
✕
2 ch/4 Ω + 70 W
✕
1
ch/2 Ω (for subwoofer)
Continuous power output....27 W
✕
4 (DIN 45324,
+B=14.4 V)
Load impedance...................4 Ω (4 – 8 Ω [2 Ω for 1 ch]
allowable)
Preout max output level/output impedance
............................................2.0 V/100 ohm
Equalizer (3-Band Parametric Equalizer):
Low
Frequency .............40/80/100/160 Hz
Q Factor.................0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain .......................±12dB
Mid
Frequency .............200/500/1k/2k Hz
Q Factor.................0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain .......................±12dB
High
Frequency .............3.15k/8k/10k/12.5k Hz
Q Factor.................0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain .......................±12dB
Loudness contour
Low ................................+3.5 dB (100 Hz), +3 dB (10
kHz)
Mid.................................+10 dB (100 Hz), +6.5 dB
(10 kHz)
High.......................+11 dB (100 Hz), +11 dB
(10 kHz)
(volume: –30 dB)
Tone controls:
Bass
Frequency .............40/63/100/160 Hz
Gain .......................±12dB
Treble
Frequency .............2.5k/4k/6.3k/10k Hz
Gain .......................±12dB
HPF:
Frequency .....................50/80/125 Hz
Slope..............................–12 dB/oct
Subwoofer:
Frequency .....................50/80/125 Hz
Slope..............................–18 dB/oct
Gain ...............................±12dB
Phase ............................Normal/Reverse
DVD Drive
System...................................DVD-Video, Compact disc
audio, MP3 system
Usable discs .........................DVD-Video, Compact disc,
MP3
Region number.....................2
Signal format:
Sampling frequency.....44.1/48/96 kHz
Number of quantization bits
....................................16/20/24; linear
Frequency response.............5 – 44,000 Hz (with DVD, at
sampling frequency 96 kHz)
Signal-to-noise ratio.............97 dB (1 kHz) (IEC-A net-
work)
