M7300
LTE-Advanced Mobile Wi-Fi User Guide
-44-
Appendix C: Specifications
General
Standards
IEEE 802.11b/g/n 2.4GHz
Network Type
4G:FDD-LTE
3G: DC-HSPA+/HSPA/UMTS 2G: EDGE/GRPS/GSM
Certification
CE, RoHS
Dimension
4.0×2.5×0.6 in. (102.6×63×16mm)
Interface
One Micro USB port, One SIM card slot, One Micro SD Memory card slot
Button
Power On/Off Button, RESET button
LED Display
Wi-Fi Status
Internet Connection Status
Battery Status
Power Supply
Internal 2000mAh Rechargeable Li-ion Battery
5VDC/1.0A External Power Adapter
Wireless
WWAN Band
FDD-LTE (800/900/1800/2100/2600MHz)
DC-HSPA+/HSPA/UMTS (900/2100MHz)
EDGE/GPRS/GSM (850/900/1800/1900MHz)
Data Rate
Download: 150Mbps
Upload: 50Mbps
Wi-Fi Frequency
2.4GHz
EIRP
<33dBm
Wi-Fi Security
Support WPA-PSK/WPA2-PSK, Wireless MAC Filtering
Antenna
Internal Antenna
Environment
Temperature
Operating : 0℃~35℃
Storage: -20℃~60℃
Humidity
Operating: 10% ~ 90% RH, Non-condensing
Storage: 5% ~ 90% RH, Non-condensing
