Tp-Link TX-6610 V2 [21/34] Management

TX-6610 1-Port Gigabit GPON Terminal User Guide

 IP Address: Enter the ONT’s local IP Address, then you can access to the Web-based Utility

via the IP Address, the default value is 192.168.1.1.

 Subnet Mask: Enter the ONT’s Subnet Mask, the default value is 255.255.255.0.

Click Save And Reboot to make the settings take effect.



Note:

If you change the IP Address of LAN, you must use the new IP Address to log in the ONT.

4.4 Management

Choose menu “Management”, and you will see the submenus under the main menu: User

management, Firmware Upgrade, Factory Defaults and Reboot. Click any one of them, and

you will be able to configure the corresponding function. The detailed explanations for each

submenu are provided below.

4.4.1 User Management

Choose menu “Management”  “User Management”, and then you can change the factory

default user name and password of the ONT in the next screen as shown in Figure 4-5. TX-6610

provides two users: admin/admin and user/user. Both can be used to log in the management

page.

Figure 4-5

It is strongly recommended that you should change the factory default user name and password of

the ONT, because all users who try to access the ONT's Web-based utility will be prompted for the

ONT's default user name and password.
