Tp-Link TL-PA7010P KIT V1 [11/16] Add another powerline adapter
![Tp-Link TL-PA7010P KIT V1 [11/16] Add another powerline adapter](/views2/1469508/page11/bgb.png)
8
Chapter 2
Use Your Powerline Adapter
2. 4. Add Another Powerline Adapter
Add a new powerline adapter into the existing powerline network
to extend my network.
For example, I’ve already set up a powerline network using
powerline devices, but the network does not reach everywhere I
need it to. I purchased another one to further extend my network.
1. Plug the new powerline adapter into a wall outlet near one of
the existing powerline devices.
Powerline
1000Mbps
1000Mbps
Pair
1000Mbps
2. Wait for a minute, and check whether the Powerline LED
stays on. If it’s on, skip to step 3. If it’s not, continue with
step 2 to pair the new powerline adapter into the secured
powerline network.
a . Press the Pair button on one of the existing powerline
devices for 1 second. Its Power LED starts blinking.
b . Within two minutes, press the Pair button on the new
powerline adapter for 1 second. Its Power LED starts
blinking. When the Powerline LED stays on and solid,
the pairing process is complete.
Existing
Powerline Device
New
Powerline Device
6
within 2 minutes
Blinking
Pair
1000Mbps
Pair
1000Mbps
Blinking
On
3. Relocate the new powerline adapter to the place where wired
Internet access is needed.
I want to:
How can I
do that?
