Tp-Link TL-PA8010 KIT V1 [7/25] Chapter 1 introduction

TL-PA8010

AV1200 Gigabit Powerline Adapter

Chapter 1 Introduction

This device is an AV1200 Gigabit Powerline Adapter which transforms your house’s existing electrical

wiring into a ubiquitous networking infrastructure. Simply plug this AV1200 Gigabit Powerline Adapter

into an ordinary AC power outlet which will easily extend your Cable/xDSL broadband connection or

existing Ethernet (LAN) network to any other electrical outlet in any room of a house without the need of

any new cabling.

This powerline adapter supports up to 1200Mbps data rate over the existing household power circuit.

With data rates of 1200Mbps, full multimedia application can easily be supported throughout the whole

house in addition to Internet access. This powerline adapter uses the existing power lines installed in a

home as a path to transmit digital data, voice, audio and video between devices.

To ensure data communication’s security and multimedia applications, this powerline adapter supports

built-in 128-bit AES encryption and Quality of Service (QoS) features. With minimum setup, you can

install and use this powerline adapter within minutes. The adapter adds two useful functions.

1． Existing connection with a new unassociated device added via the Pair Button.

2． Reset to default setting via the Management Utility or the Pair Button.

1.1 System Requirement

a) At least two AC power outlets (100–240V~, 50/60Hz) with standard home power wiring

b) A computer with the following:

 Operating System with TCP/IP installed

 Pentium III compatible processor and above

 Ethernet LAN card installed with TCP/IP protocol

 64 MB RAM or more

 50 MB of free disk space (Minimum)

1.2 Important Safety Instructions

1. Do not open this product or attempt to service it; it may expose you to dangerous high voltage or

other risks.

2. Do not operate this product near water.

3. Do not place or operate this product near a radiator or a heat register.

4. Do not expose this product to dampness, dust or corrosive liquids.

5. Do not connect this product or disconnect it from a wall socket during a lightning or a thunderstorm

6. Do not block the ventilation slots of this product, for insufficient airflow may harm it.

7. Do not put anything on this product.

8. Plug this product directly into a wall socket (100–240V~, 50/60Hz). Do not use an extension cord

between this product and the AC power source.

9. When plugging this product into a wall socket, make sure that the electrical socket is not damaged,

and that there is no gas leakage.

10. Place the connecting cables properly so that people won’t stumble or walk on it.

11. This product should be operated from the type of power indicated on the marking label. If you are not

sure of the type of power available, consult the qualified technician.
