Gigabyte GA-780T-USB3 (rev. 3.1) [38/96] Halt on

BIOS Setup - 38 -

Halt On

Allows you to determine whether the system will stop for an error during the POST.

All Errors Whenever the BIOS detects a non-fatal error the system boot will stop.

No Errors The system boot will not stop for any error.

All, But Keyboard The system boot will not stop for a keyboard error but stop for all other errors.

(Default)

Memory

These elds are read-only and are determined by the BIOS POST.

Base Memory Also called conventional memory. Typically, 640 KB will be reserved for the

MS-DOS operating system.

Extended Memory The amount of extended memory.
