Appendix- 69 -
English
After the creation is completed, you can see detailed information about the RAID Array in the DISK/
VOLUME INFORMATION section, including RAID mode, disk block size, disk name, and disk capacity,
etc.
To exit the ICH7M-DH RAID BIOS utility, press ESC in Main Menu.
Now, you can proceed to the installation of the SATA driver and operating system.
Delete RAID Volume
If you want to delete a RAID volume, select the Delete RAID Volume option in Main Menu. Press
ENTER and follow on-screen instructions.
Figure 10
Intel(R) Matrix Storage Manager option ROM v5.7.0.1007 ICH7MR
Copyright(C) 2003-05 Intel Corporation. All Rights Reversed.
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes :
ID Name Level Strip Size Status Bootable
0 Volume0 RAID(Stripe) 128KB 223.6GB Normal Yes
Physical Disks :
Port Driver Model Serial # Size Type/Status(Vol ID)
0 ST3120026AS 3JT329JX 111.8GB Member Disk(0)
2 ST3120026AS 3JT354CP 111.8GB Member Disk(0)
[]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Matrix Storage Manager option ROM v5.7.0.1007 ICH7MR
Copyright(C) 2003-05 Intel Corporation. All Rights Reversed.
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes :
ID Name Level Strip Size Status Bootable
0 Volume0 RAID(Stripe) 128KB 223.6GB Normal Yes
Physical Disks :
Port Driver Model Serial # Size Type/Status(Vol ID)
0 ST3120026AS 3JT329JX 111.8GB Member Disk(0)
2 ST3120026AS 3JT354CP 111.8GB Member Disk(0)
[]-Select [ESC]-Exit [ENTER]-Select Menu
Figure 11
