4.Quick Start
7
①
Power socket
AC input connector
②
Fuse
The rating is
100 - 120 V
250 V, F1AL
220 - 240 V
250 V, F0.5AL
③
Power switch
Switch between 110 V and 220 V.
④
USB (type B)
connector
This can be used to connect a USB type B controller.
Connect with an external device, such as connected to a PC
and controlled via PC software.
⑤
Ext Mod In
Connector
External modulation input, use it as external signal source.
⑥
Ext Trig/Burst/Fsk
In connector
This signal can be used as external signal source in Sweep,
Burst and FSK mode.
⑦
Ref Clk/Counter In
connector
To accept an external clock signal, or to accept the input
signal of counter. (See page 40, To Set the Counter)
⑧
Ref Clk Out
connector
To synchronize generators. Output a clock signal generated
by the crystal inside the generator. (See page 40, To Set the
Clock Source)
⑨
P-Output
connector
Signal output for the Power Amplifier.
See page 41,
To Use the Power Amplifier (Optional)
⑩
P-Input connector
Signal input for the Power Amplifier.
See page 41,
To Use the Power Amplifier (Optional)
User Interface
④
⑨
⑧
③
⑦
②
①
⑥
⑤
⑩
⑪
Figure 4-3 User interface (take Sine for instance)
