Tp-Link T1500-28PCT V3 Инструкция по установке онлайн
Business Networking Solution
Installation Guide
Jetstream Smart Switch
T1500G-10MPS / T1600G-28TS / T1600G-28PS
T1500-28TC (TL-SL2428) / T1500-28PCT (TL-SL2428P)
T1600G-18TS (TL-SG2216) / T1600G-52TS (TL-SG2452)
T1600G-52PS (TL-SG2452P) / T1700G-28TQ / T1700X-16TS
Содержание
- Business networking solution 1
- Installation guide 1
- Jetstream smart switch 1
- About this installation guide 3
- Audience 3
- Conventions 3
- Related document 3
- Appendix a troubleshooting 14 4
- Appendix b specifications 15 4
- Chapter 1 introduction 01 4
- Chapter 2 installation 08 4
- Chapter 3 connection 12 4
- Contents 4
- Appearance 5
- Chapter 1 introduction 5
- Front panel 5
- Jetstream smart switch 5
- Product overview 5
- Introduction 6
- Jetstream smart switch 6
- The front panel of t1500g 10mps is shown as the following figure 6
- The front panel of t1600g 18ts tl sg2216 is shown as the following figure 6
- The front panel of t1600g 28ps is shown as the following figure 6
- The front panel of t1600g 28ts is shown as the following figure 6
- The front panel of the t1600g 52ts tl sg2452 is shown as the following figure 6
- For t1500 28tc tl sl2428 t1600g 18ts tl sg2216 t1600g 28ts t1600g 52ts tg sg2452 t1700g 28tq t1700x 16ts 7
- Jetstream smart switch 7
- The front panel of the t1600g 52ps tl sg2452p is shown as the following figure 7
- The front panel of the t1700g 28tq is shown as the following figure 7
- The front panel of the t1700x 16ts is shown as the following figure 7
- Jetstream smart switch 8
- T1500 28pct tl sl2428p t1500g 10mps t1600g 28ps t1600g 52ps tl sg2452p has an led mode switch button which is used to switch the led status indication when the speed led is on the port led is indicating the data transmission rate when the poe led is on the port led is indicating the power supply status by default the speed led is on pressing the mode switch button the speed led will turn off and the poe led will light up then the poe led will turn off after being on for 60 seconds and the speed led will light up again 8
- Jetstream smart switch 9
- 100 1000mbps rj45 port 10
- 100mbps rj45 port 10
- Designed to connect to the device with a bandwidth of 10mbps 100mbps or 1000mbps 10
- Designed to connect to the device with a bandwidth of 10mbps or 100mbps 10
- Designed to display the stack unit id of the switch for the switch that does not join any stack system it displays its default unit id to modify the default unit number please logon to the gui of the s w i t c h and go to stack stack management stack config page and configure the new unit id the new unit id will take effect after you reboot the switch 10
- Designed to install the sfp module for t1500 t1500g and t1600g series products the switch features some slots that are shared with the associated rj45 ports the associated two ports are referred as a combo port which means they cannot be used simultaneously otherwise only sfp port works 10
- Designed to install the sfp module for t1700g 28tq and t1700x 16ts the switch supports 1g or 10g sfp module connection 10
- Jetstream smart switch 10
- Led mode switch button 10
- Port feature 10
- Press this button to switch the led status indication between speed and poe 10
- Sfp port 10
- Unit id led 10
- With the switch powered on press reset button for 5 seconds to reset the software setting to its factory default settings 10
- Grounding terminal 11
- Jetstream smart switch 11
- Kensington security slot 11
- Power socket 11
- Rear panel 11
- Chapter 2 installation 12
- Jetstream smart switch 12
- Package contents 12
- Safety precautions 12
- Site requirements 12
- Jetstream smart switch 13
- Desktop installation 14
- Installation tools 14
- Jetstream smart switch 14
- Product installation 14
- Jetstream smart switch 15
- Rack installation 15
- Chapter 3 connection 16
- Ethernet port 16
- Jetstream smart switch 16
- Sfp sfp port 16
- Verify installation 16
- Accessing the switch 17
- Initialization 17
- Jetstream smart switch 17
- Power on 17
- Appendix a troubleshooting 18
- Jetstream smart switch 18
- Please try the following 18
- Press the reset button for at least 5 seconds to reset the system the system will be reset to the factory default settings and the default login user name and password are both admin 18
- Q1 what could i do if i forgot the username and password of the switch 18
- Q2 why does the pwr power led work abnormally 18
- Q3 what should i do if i cannot access the web management page 18
- The pwr power led should be lit up when the power system works normally if the pwr led worked abnormally please take the following steps 18
- Appendix b specifications 19
- Jetstream smart switch 19
- Ce mark warning 20
- Eu declaration of conformity 20
- Fcc statement 20
- Safety information 20
- Bsmi notice 21
- Explanation of the symbols on the product label 21
- Industry canada statement 21
- 安全諮詢及注意事項 21
- 限用物質含有情況標示聲明書 21
- For technical support user guide and other information please visit 24
- Http www tp link com support or simply scan the qr code 24
