Installation Guide

Smart PoE Switch

T1500-28PCT (TL-SL2428P)

Business Networking Solution

Содержание

Ce mark warning 3
Copyright trademarks 3
Fcc statement 3
About this installation guide 4
Related document 4
Audience 5
Conventions 5
Network administrator 5
Network engineer 5
This guide uses the specific formats to highlight special messages the following table lists the notice icons that are used throughout this guide 5
This installation guide is for 5
Appendix a troubleshooting 19 6
Appendix b hardware specifications 20 6
Chapter 1 introduction 01 6
Chapter 2 installation 05 6
Chapter 3 lightning protection 10 6
Chapter 4 connection 16 6
Chapter 5 login to the switch 18 6
Contents 6
Appearance 7
Chapter 1 introduction 7
Figure 1 1 front panel of t1500 28pct 7
Front panel 7
Pd a device powered by a pse and thus consumes energy examples include powering network cameras wireless lan access points ip telephones network hubs embedded computers etc 7
Poe this technology describes a system to transmit electrical power along with data to remote devices over standard twisted pair cable in an ethernet 7
Product overview 7
Pse a device switch or hub for instance that provides power through an ethernet cable 7
T1500 28pct integrates multiple functions with excellent performance and are friendly to manage which can fully meet the need of the users demanding higher networking performance 7
T1500 28pct is compliant with the ieee802 ethernet protocols 7
T1500 28pct smart poe switch is also a power sourcing equipment pse all the fast ethernet rj45 ports on the switch support power over ethernet poe function which can automatically detect and supply power with those powered devices pds complying with ieee 802 af and ieee 802 at 7
The front panel of t1500 28pct is shown as figure 1 1 7
The switch is equipped with powerful management interface via which system port network vlan and priority can be configured they provide a variety of service features and multiple powerful functions with high security the eia standardized framework and smart configuration capacity can provide flexible solutions for a variable scale of networks qos and igmp snooping filtering optimize voice and video application snmp rmon web log in bring abundant management policies 7
T1500 28pct has an led mode switch button which is for switching the led status indication when the 10 100m led is on the port led is indicating the data transmission rate when the poe led is on the port led is indicating the power supply status by default the 10 100m led is on pressing the mode switch button the 10 100m led will turn off and the poe led will light up then the poe led will turn off after being on for 60 seconds and the 10 100m led will light up again 8
When the 10 100m is on the port led is indicating the data transmission rate 8
When the poe led is on the port led is indicating the power supply status 8
100 1000mbps rj45 port 9
100mbps rj45 port 9
Designed to connect to the device with a bandwidth of 10mbps 100mbps or 1000mbps each has a corresponding 1000m led 9
Designed to connect to the device with a bandwidth of 10mbps or 100mbps each has a corresponding 10 100m or poe led 9
Designed to install the sfp module t1500 28pct features some sfp transceiver slots that are shared with the associated rj45 ports the associated two ports are referred as a combo port which means they cannot be used simultaneously otherwise only sfp port works meanwhile the associated two ports share the same led for t1500 28pct port 27 shares the same led with port 27f and port 28 shares the same led with port 28f 9
Model 10 100mbps rj45 port 10 100 1000mbps rj45 port sfp port 9
Port feature 9
Sfp port 9
T1500 28pct 24 4 2 9
With the switch powered on press reset button for 5 seconds to reset the software setting to its factory default settings 9
Grounding terminal 10
Kensington security slot 10
Power socket 10
Rear panel 10
Before cleaning the device cut off the power supply do not clean it by the waterish cloth and never use any other liquid cleaning method 11
Chapter 2 installation 11
Do not open or remove the cover of the switch 11
Ensure the vent hole is well ventilated and unblocked 11
Keep the power off during the installation 11
Make sure that the package contains the following items if any of the listed items is damaged or missing please contact your distributor 11
Make sure that the supply voltage matches the specifications indicated on the rear panel of the switch 11
Package contents 11
Safety precautions 11
To avoid any device damage and bodily injury caused by improper use please observe the following rules 11
Use only the power cord provided with the switch 11
Wear an esd preventive wrist strap and make sure that the wrist strap has a good skin contact and is well grounded 11
Clearness 12
Electromagnetic interference 12
Site requirements 12
Temperature humidity 12
Installation site 13
Installation tools 13
Lightening protection 13
Cables 14
Check the grounding and stability of the rack 14
Desktop installation 14
Esd preventive wrist wrap 14
Installation 14
Note these tools are not provided with our product if needed please self purchase them 14
Product installation 14
Rack installation 14
Remove the adhesive backing papers from the rubber feet 14
Secure the supplied rack mounting brackets to each side of the device with supplied screws as illustrated in the following figure 14
Set the device on a flat surface strong enough to support the entire weight of the device with all fittings 14
Smart poe switch 14
To install the device in an eia standard sized 19 inch rack follow the instructions described below 14
To install the device on the desktop please follow the steps 14
Turnover the device and attach the supplied rubber feet to the recessed areas on the bottom at each corner of the device 14
Cabling reasonably 16
Chapter 3 lightning protection 16
Requirements for cabling outdoors 16
Note the above minimum net length height is required when metal raceway is not used if any requirements cannot be met you can add a steel tube or metal raceway for shielding 17
Requirements for cabling indoors 17
Requirements for the distance between ethernet cable and high power electric devices are in following tables 17
Requirements for the distance between ethernet cable and other pipelines are shown in the table 17
The main cable should be paved in the metal raceway of the access shaft when cabling keep the loop area formed by the cable itself as small as possible 17
The two diagrams below demonstrate parallel net length and parallel overlapping net height 17
When cabling indoors keep a certain distance away from the devices that may cause high frequency interferences such as down conductor cable powerline power transformer and electromotor 17
Connect to ground 18
Connecting the device to ground is to quickly release the lightning over voltage and over current of the device which is also a necessary measure to protect the body from electric shock 18
Connecting to the grounding bar 18
If the device is installed in the equipment room where a grounding bar is available you are recommended to connect the device to the grounding bar as shown in the following figure 18
In different environments the device may be grounded differently the following will instruct you to connect the device to the ground in two ways connecting to the grounding bar or connecting to the ground via the power cord please connect the device to ground in the optimum way according to your specific operation environment 18
Connecting to the ground via the power supply 19
Equipotential bonding 19
Use lightning arrester 20
Chapter 4 connection 22
Ethernet port 22
Sfp port 22
Initialization 23
Power on 23
Verify installation 23
Chapter 5 login to the switch 24
Appendix a troubleshooting 25
Q1 what could i do if i forgot the username and password of the switch 25
Q2 why does the pwr led work abnormally 25
Q3 what could i do if i could not access the web based configuration page 25
Appendix b hardware specifications 26
