02
Smart PoE Switch
LEDs
T1500-28PCT has an LED mode switch button which is for switching the LED
status indication. When the 10/100M LED is on, the port LED is indicating the data
transmission rate. When the PoE LED is on, the port LED is indicating the power
supply status. By default, the 10/100M LED is on. Pressing the mode switch button,
the 10/100M LED will turn off and the PoE LED will light up. Then the PoE LED will
turn off after being on for 60 seconds and the 10/100M LED will light up again.
When the 10/100M is on, the port LED is indicating the data transmission rate.
LED Status Indication
PWR
On The switch is powered on
Off The switch is powered off or power supply is abnormal
Flashing Power supply is abnormal
SYS
Flashing The switch works properly
On/Off The switch works improperly
FAN
Green All the fans work properly
Yellow Not all the fans work properly
PoE Max
On The remaining PoE power≤
7W
Flashing
The remaining PoE power keeps ≤
7W after this LED is
on for 2 minutes
Off The remaining PoE power＞
7W
10/100M
or PoE
Green
On
A 100Mbps device is connected to the corresponding
port, but no activity
Flashing Data is being transmitted or received
Yellow
On
A 10Mbps device is connected to the corresponding
port, but no activity
Flashing Data is being transmitted or received
Off No device is connected to the corresponding port
1000M
Green
On
A 1000Mbps device is connected to the corresponding
port, but no activity
Flashing Data is being transmitted or received
Yellow
On
A 10/100Mbps device is connected to the corresponding
port, but no activity
Flashing Data is being transmitted or received
Off No device is connected to the corresponding port
When the PoE LED is on, the port LED is indicating the power supply status.
LED Status Indication
PWR
On The switch is powered on
Off The switch is powered off or power supply is abnormal
Flashing Power supply is abnormal
SYS
Flashing The switch works properly
On/Off The switch works improperly
Introduction
