20
Smart PoE Switch
Appendix B Hardware Specifications
Item Content
Standards and Protocol IEEE 802.3i 10Base-T
IEEE 802.3u 100Base-TX/100Base-FX
IEEE 802.3ab 1000Base-T
IEEE802.3ad Link Aggregation
IEEE 802.3z 1000Base-X
IEEE 802.3x Flow Control
IEEE802.1p QoS
IEEE802.1q VLAN
IEEE802.1d Spanning Tree Protocol
IEEE802.1s Multi Spanning Tree Protocol
IEEE802.1w Rapid Spanning Tree Protocol
Transmission Medium 10Base-T: UTP/STP of Cat. 3 or above
100Base-TX: UTP/STP of Cat. 5 or above
1000Base-T: 4-pair UTP (≤100m) of Cat. 5e and Cat. 6 or
above
1000Base-X: MMF or SMF SFP Module(Optional)
LEDs
PWR, SYS, PoE MAX, FAN, 10/100M or PoE, 1000M LEDs
Operating Temperature 0℃
~
40℃
Storage Temperature -40℃
~
70℃
Operating Humidity 10%
~
90%RH Non-condensing
Storage Humidity 5%
~
90%RH Non-condensing
Hardware Specifications
