Tp-Link T1500-28PCT V1 [5/28] Audience

III

Audience

This Installation Guide is for:

Network Engineer

Network Administrator

Conventions

This Guide uses the specific formats to highlight special messages. The following

table lists the notice icons that are used throughout this guide.

Remind to be careful. A caution indicates a potential which may result in

device damage.

Remind to take notice. The note contains the helpful information for a

better use of the product.
