JetStream Smart Switch
05Introduction
LED Indication
PWR
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
SYS
Flashing: The switch works properly.
On or Off: The switch works improperly.
FAN
Green: All the fans work properly.
Yellow: Not all the fans work properly.
PoE Max
(When the PoE LED
is on)
On: The remaining PoE power≤7W.
Flashing: The remaining PoE power keeps≤7W after this LED is on for 2 minutes.
Off: The remaining PoE power
＞
7W.
10/100M or PoE
(When the Speed
LED is on)
Green On: Running at 100Mbps, but no activity.
Green Flashing: Running at 100Mbps and is transmitting or receiving data.
Yellow On: Running at 10Mbps, but no activity.
Yellow Flashing: Running at 10Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: Only for T1500-28PCT.
1000M
Speed or PoE
(When the Speed
LED is on)
Green On: Running at 1000Mbps, but no activity.
Green Flashing: Running at 1000Mbps and is transmitting or receiving data.
Yellow On: Running at 10/100Mbps, but no activity.
Yellow Flashing: Running at 10/100Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: 1000M for T1500-28PCT. Speed or PoE for T1500G-10MPS, 1-24 ports of
T1600G-28PS and 1-48 ports of T1600G-52PS (TL-SG2452P)
10/100M or PoE
Speed or PoE
(When the PoE LED
is on)
Green On: The port is supplying power normally.
Green Flashing: The supply power exceeds the correponding port's maximum power.
Yellow On: Overload or short circuit is detected.
Yellow Flashing: Power-on self-test failed.
Off: Not providing PoE power on the port.
Note: 10/100M or PoE for T1500-28PCT. Speed or PoE for T1500G-10MPS, 1-24 ports
of T1600G-28PS and 1-48 ports of T1600G-52PS (TL-SG2452P)
1000Base-X
(When the Speed
LED is on)
On:
A 1000Mbps device is connected to the corresponding port.
Flashing:
The corresponding port is transmitting or receiving data.
Off: A 10/100Mbps device or no device is connected to the corresponding port.
Note: For 25-28 ports of T1600G-28PS and 49-52 ports of T1600G-52PS (TL-SG2452P)
.
SFP1, SFP2
Green On: A 1000Mbps device is linked to the corresponding port, but no activity.
Green Flashing: A 1000Mbps device is linked to the corresponding port and data is
being transmitted or received.
Yellow On: A 10/100Mbps device is linked to the corresponding port, but no activity.
Yellow Flashing: A 10/100Mbps device is linked to the corresponding port and is
transmitting or receiving data.
Off: No device is linked to the corresponding port but no activity.
Note: Only for T1500G-10MPS.
