RIGOL Chapter 5 Specifications
5-4 DP800A User’s Guide
Mechanical
Dimensions 239mm(W) x 157mm(H) x 418mm(D)
Weight
DP831A: 9.75kg
DP832A: 10.5kg
DP821A: 10.0kg
DP811A: 10.3kg
Power
AC Input (50Hz-60Hz)
100Vac±10%, 115Vac±10%, 230Vac±10% (maximum 250Vac）
Maximum Input Power
DP831A: 416VA
DP832A: 521VA
DP821A: 450VA
DP811A: 503VA
I/O
USB DEVICE 1
USB HOST 1
LAN 1
RS232 1
Digital IO 1
USB-GPIB
1 (Option, extend a GPIB interface using the USB-GPIB interface
converter)
Rear Output Interface 1 for DP811A
Environment
Cooling Method Fan Cooling
Working Temperature
0℃ to 40℃
Storage Temperature
-40℃ to 70℃
Humidity 5% to 80% relative humidity
Altitude Below 1500m
Note
[1]
: The accuracy parameters are acquired via calibration under 25℃ after 1-hour
warm-up.
Note
[2]
: The maximum time required for the output to change accordingly after receiving the
APPLy and SOURce commands.
Note
[3]
: The variation of the output within 8 hours after 30-minute warm-up when the load
circuit and environment temperature are constant.
