Rigol DP821A [49/146] Installation procedures

Chapter 1 Quick Start RIGOL

DP800A User’s Guide 1-31

Installation Procedures

CAUTION

Only authorized operator can execute the installation operation. Improper

installation might result in damage of the instrument or incorrect

installation of the instrument onto the rack.

1. Remove the four rubber bumpers at the front and rear panels of the two

instruments respectively.

2. Fix the two instruments onto the rack support shelf using two M4 screws

respectively.

3. Fix the left fixing part at the left side of the front panel of instrument A using two

M4 screws.

Instrument A Instrument B
