Gigabyte GA-8IP900MK [35/96] English
![Gigabyte GA-8IP900MK [35/96] English](/views2/1047366/page35/bg23.png)
- 31 - Hardware Installation Process
English
22) CLR_PWD
When Jumper is set to "open" and system is restarted, the password that is set w ill be cleared.
On the contrary when Jumper is set to "close", the current status remains.
1
1
Open: Clear Password
Close: Normal
