- 72 -
GA-8IP900MK Motherboard
English
SPDIF Output Device (Optional Device)
3. Connect co-axial or optical output to the AC3
decoder.
1. Connect the SPDIF output device to the rear
bracket of PC, and fix it with screw.
2. Connect SPDIF wire to the m otherboard.
A "S/PDIF output" devi ce is available on the
motherboard. Cable with rear bracket is provided
and could link to the "S/PDIF output" connector (As
picture.) For the further linkage to decoder, rear
bracket provides coaxial cable and Fiber connect-
ing port.
8ip900mk_1001_t.p65 2003/4/22, 下午 03:5672
