Содержание
- Mother board ga 8i865pe tw 3
- Ga 8i865pe tw p4 titan series motherboard 5
- User s manual 5
- Chapter 1 introduction 6
- Chapter 2 hardware installation process 6
- Chapter 3 bios setup 1 6
- English 6
- Table of contents 6
- Warning 6
- Chapter 4 technical reference 9 7
- Chapter 5 appendix 3 7
- English 7
- English 8
- Installing the motherboard to the chassis 8
- Warning 8
- Chapter 1 introduction 9
- English 9
- Features summary 9
- English 10
- English 11
- Ga 8i865pe tw 11
- Ga 8i865pe tw motherboard layout 11
- Hyper threading 11
- P4 titan 11
- Block diagram 12
- English 12
- Chapter 2 hardware installation process 13
- English 13
- Angling the rod to 6 14
- Before installing the processor adhere to the following warning 14
- English 14
- Ht functionality requirement content 14
- Pin1 indicator 14
- Socket actuation lever 14
- Step 1 1 cpu installation 14
- Step 1 install the central processing unit cpu 14
- English 15
- Step 1 2 cpu cooling fan installation 15
- Before installing the memory modules please comply with the following conditions 1 please make sure that the memory used is supported by the motherboard it is recommended that memory of similar capacity specifications and brand be used 2 before installing or removing memory modules please make sure that the computer power is switched off to prevent hardware damage 3 memory modules have a foolproof insertion design a memory module can be in stalled in only one direction if you are unable to insert the module please switch the direction 16
- Capacity and specifications memory modules are designed so that they can be inserted only in one direction the memory capacity used can differ with each slot 16
- English 16
- Step 2 install memory modules 16
- The motherboard supports ddr memory modules whereby bios will automatically detect memory 16
- 13 hardware installation process 17
- English 17
- Figure 1 dual channel technology ds double side ss single side 17
- Figure 2 don t operate dual channel technology ds double side ss single side 17
- Please note that those types not in the tables will not boot up 17
- Same color in order for dual channel technology to work 17
- The following tables include all memory installed combination types 17
- Three ddr memory modules are installed please note that the dual channel technology will not operate when three ddr memory modules are installed part of them will not be detected 4 four ddr memory modules are installed if you install four memory modules at the same time the dual channel technology will operate only when those modules have the same memory size and type 17
- We ll strongly recommend our user to slot two ddr memory modules into the dimms with the 17
- Bottleneck by doubling the memory bandwidth nowadays with the highest bandwidth of 3 gb s of ddr400 memory and complete line of ddr400 333 266 200 memory solutions ddr memory 18
- Ddr introduction 18
- Ddr memory is a great evolutionary solution for the pc industry that builds on the existing sdram architecture yet make the awesome advances in solving the system performance 18
- English 18
- Established on the existing sdram infrastructure ddr double data rate memory is a high 18
- Is the best choice for building high performance and low latency dram subsystem that are suitable for servers workstations and full range of desktop pcs 18
- Performance and cost effective solution that allows easy adoption for memory vendors oems and system integrators 18
- Agp card 19
- English 19
- Read the related expansion card s instruction document before install the expansion card into the computer 2 remove your computer s chassis cover necessary screws and slot bracket from the computer 3 press the expansion card firmly into expansion slot in motherboard 4 be sure the metal contacts on the card are indeed seated in the slot 5 replace the screw to secure the slot bracket of the expansion card 6 replace your computer s chassis cover 7 power on the computer if necessary setup bios utility of expansion card from bios 8 install related driver from the operating system 19
- Step 3 install expansion cards 19
- English 20
- Ps 2 keyboard and ps 2 mouse connector 20
- Step 4 1 i o back panel introduction 20
- Step 4 install i o peripherals cables 20
- Usb lan connector 20
- Audio connectors 21
- English 21
- If you want the detailed information for 2 4 6 8 channel audio setup installation please refer to page 61 21
- Parallel port serial ports coma comb 21
- Atx_12v 2 atx power connector 22
- Cd_in 15 aux_in 22
- Clr_cmos 22
- Cpu_fan 4 sys_fan 22
- English 22
- F_audio 13 sur_cen 22
- F_usb1 f_usb2 19 game 22
- Fdd 6 ide1 ide2 22
- Info_link 21 ci 22
- Pwr_led 10 f_panel 22
- Sata0 sata1 8 2x_det 22
- Spdif_io 17 ir_cir 22
- Step 4 2 connectors jumper setting introduction 22
- 19 hardware installation process 23
- 2 atx_12v atx power connector 23
- English 23
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector please make sure that all components and devices are properly installed align the power connector with its proper location on the motherboard and connect tightly the atx_12v power connector mainly supplies power to the cpu if the atx_12v power connector is not connected the system will not start caution please use a power supply that is able to handle the system voltage requirements it is recommended that a power supply that can withstand high power consumption be used 300w or greater if a power supply is used that does not provide the required power the result can lead to an unstable system or a system that is unable to start 23
- 4 cpu_fan sys_fan cooler fan power connector 24
- English 24
- Fdd fdd connector 24
- 21 hardware installation process 25
- English 25
- Ide1 ide2 ide1 ide2 connector 25
- Please connect first hard disk to ide1 and connect cdrom to ide2 the red stripe of the ribbon cable must be the same side with the pin1 25
- Sata0 sata1 serial ata connector 25
- You can connect the serial ata device to this connector 25
- 2x_det 26
- English 26
- Pwr_led 26
- 23 hardware installation process 27
- English 27
- F_panel 2x10 pins connector 27
- Please connect the power led pc peaker reset switch and power switch etc of your chassis front panel to the f_panel connector according to the pin assignment below 27
- 24 ga 8i865pe tw motherboard 28
- Bat battery 28
- Danger of explosion if battery is incorrectly 28
- English 28
- F_audio front audio connector 28
- If you want to use front audio connector you must remove 5 6 9 10 jumper in order to utilize the front audio header your chassis must have front audio connector also please make sure the pin assigment on the cable is the same as the pin assigment on the mb header to find out if the chassis you are buying support front audio connector please contact your dealer please note you can have the alternative of using front audio connector or of using rear audio connector to play sound 28
- Manufacturer s instructions if you want to erase cmos 1 please turn off the computer and unplug the power 2 remove the battery wait for 30 second 3 re install the battery 4 plug the power cord and turn on the computer 28
- Recommended by the manufacturer dispose of used batteries according to the 28
- Replace only with the same or equivalent type 28
- Replaced 28
- 25 hardware installation process 29
- Cd_in cd in connector 29
- Connect cd rom or dvd rom audio out to the connector 29
- English 29
- Please contact your nearest dealer for optional sur_cen cable 29
- Sur_cen surround center connector 29
- 26 ga 8i865pe tw motherboard 30
- Aux_in aux in connector 30
- Connect other device such as pci tv tunner audio out to the connector 30
- English 30
- Spdif_io spdif in out connector 30
- The spdif output is capable of providing digital audio to external speakers or compressed ac3 data to an external dolby digital decoder use this feature only when your stereo system has digital input output function be careful with the polarity of the spdif_io connector check the pin assignment carefully while you connect the spdif cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional spdif cable please contact your local dealer 30
- 27 hardware installation process 31
- Be careful with the polarity of the front usb connector check the pin assignment carefully while you connect the front usb cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional front usb cable please contact your local dealer 31
- English 31
- F_ usb1 f_usb2 front usb connector 31
- Ir_cir 31
- To enable the ir cir function on the board you are required to purchase an option ir cir module to use ir function only please connect ir module to pin1 to pin5 be careful with the polarity of the ir cir connector check the pin assignment carefully while you connect the ir cir cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional ir cir cable please contact your local dealer 31
- 28 ga 8i865pe tw motherboard 32
- English 32
- Game game connector 32
- Info_link 32
- Pin assignment while you connect the external device cable please contact your nearest dealer for optional external device cable 32
- This connector allows you to connect some external devices to provide you extra function check the 32
- This connector supports joystick midi keyboard and other relate audio devices 32
- Ci chassis intrusion case open 33
- Clr_cmos clear cmos 33
- English 33
- English 34
- Chapter 3 bios setup 35
- Control keys 35
- English 35
- Main menu 35
- Status page setup menu option page setup menu 35
- Advanced bios features 36
- English 36
- Fail safe defaults indicates the value of the system parameters which the system would be in safe configuration 36
- Frequency voltage control 36
- Ga 8i865pe tw motherboard 32 36
- If you can t find the setting you want please press ctrl f1 to search the advanced option hidden 36
- Integrated peripherals 36
- Load fail safe defaults 36
- Load optimized defaults 36
- Optimized defaults indicates the value of the system parameters which the system would be in best performance configuration 36
- Pc health status 36
- Pnp pci configuration 36
- Power management setup 36
- Standard cmos features 36
- The main menu for example bios ver e3 36
- This setup page includes all onboard peripherals 36
- This setup page includes all the configurations of pci pnp isa resources 36
- This setup page includes all the items in standard compatible bios 36
- This setup page includes all the items of award special enhanced features 36
- This setup page includes all the items of green function features 36
- This setup page is control cpu clock and frequency ratio 36
- This setup page is the system auto detect temperature voltage fan speed 36
- To accept or enter the sub menu 36
- English 37
- Access mode use this to set the access mode for the hard drive the four options are c h s lba large auto default auto hard drive information should be labeled on the outside drive casing enter the appropriate option based on this information 38
- Cylinder number of cylinders 38
- Day the day from 1 to 31 or the maximum allowed in the month 38
- English 38
- Ga 8i865pe tw motherboard 34 38
- Head number of heads 38
- Ide channel 0 master slave ide channel 1 master slave 38
- Ide hdd auto detection press enter to select this option for automatic device detection ide primary master slave ide secondary master slave ide device setup you can use one of three methods auto allows bios to automatically detect ide devices during post default none select this if no ide devices are used and the system will skip the automatic detection step and allow for faster system start up manual user can manually input the correct settings 38
- Landing zone landing zone 38
- Month the month jan through dec 38
- Precomp write precomp 38
- Standard cmos features 38
- The time is calculated base on the 24 hour military time clock for example 1 p m is 13 00 00 38
- Week the week from sun to sat determined by the bios and is display only 38
- Year the year from 1999 through 2098 38
- Base memory 39
- Drive a drive b 39
- English 39
- Extended memory 39
- Floppy 3 mode support for japan area 39
- Halt on 39
- Memory 39
- Advanced bios features 40
- Cpu hyper threading 40
- English 40
- First second third boot device 40
- Hard disk boot priority 40
- Password check 40
- Auto when no device is plugged in ide1 or ide2 sata controller will remap to ide controller default value 41
- Bios setup 37 41
- Disabled disable onboard 1st channel ide port 41
- Disabled disable onboard 2nd channel ide port 41
- Disabled disable sata controller 41
- Enabled enable onboard 1st channel ide port default value 41
- Enabled enable onboard 2nd channel ide port default value 41
- English 41
- Integrated peripherals 41
- Manual set sata mode manually 41
- On chip primary pci ide 41
- On chip sata 41
- On chip secondary pci ide 41
- Ac97 audio 42
- English 42
- Onboard h w lan 42
- Onboard serial port 1 42
- Onboard serial port 2 42
- Sata port0 configure as 42
- Sata port1 configure as 42
- Usb 2 controller 42
- Usb controller 42
- Usb keyboard support 42
- Usb mouse support 42
- Cir port address 43
- Cir port irq 43
- Ecp mode use dma 43
- English 43
- Game port address 43
- Midi port address 43
- Midi port irq 43
- Onboard parallel port 43
- Parallel port mode 43
- Uart mode select 43
- Ur2 duplex mode 43
- Acpi suspend type 44
- Blinking in standby mode s1 power led will blink default value 44
- Date of month alarm everyday 1 31 44
- Delay 4 sec press power button 4 seconds to power off enter suspend if button is pressed less than 4 seconds 44
- Disabled disable modem ring on wake on lan function 44
- Disabled disable this function 44
- Disabled disable this function default value 44
- Dual off in standby mode s1 a if use single color led power led will turn off b if use dual color led power led will turn to another color 44
- Enabled enable alarm function to power on system if rtc alarm lead to power on is enabled 44
- Enabled enable modem ring on wake on lan default value 44
- Enabled enable pme event wake up default value 44
- English 44
- Ga 8i865pe tw motherboard 40 44
- Instant off press power button then power off instantly default value 44
- Modemringon wakeonlan 44
- Off by power button 44
- Pme event wake up 44
- Power led in s1 state 44
- Power management setup 44
- Resume by alarm 44
- S1 pos set acpi suspend type to s1 pos power on suspend default value 44
- S3 str set acpi suspend type to s3 str suspend to ram 44
- Time hh mm ss alarm 0 23 0 59 0 59 44
- You can set resume by alarm item to enabled and key in data time to power on system 44
- Ac back function 45
- English 45
- Kb power on password 45
- Power on by keyboard 45
- Power on by mouse 45
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 1 pci 5 46
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 2 46
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 3 46
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 4 46
- Auto auto assign irq to pci 1 pci 5 default value 46
- Auto auto assign irq to pci 2 default value 46
- Auto auto assign irq to pci 3 default value 46
- Auto auto assign irq to pci 4 default value 46
- English 46
- Ga 8i865pe tw motherboard 42 46
- Pci 2 irq assignment 46
- Pci 3 irq assignment 46
- Pci 4 irq assignment 46
- Pci1 pci5 irq assignment 46
- Pnp pci configurations 46
- Bios setup 43 47
- Case opened 47
- Cpu sysem fan fail warning 47
- Cpu warning temperature 47
- Current cpu system fan speed rpm 47
- Current cpu temperature 47
- Current voltage v vcore ddr25v 3 v 12v 47
- Detect cpu system fan speed status automatically 47
- Detect cpu temperature automatically 47
- Detect system s voltage status automatically 47
- Disabled disable this function default value 47
- Disabled don t reset case open status default value 47
- Disabled fan warning function disable default value 47
- Enabled clear case open status at next boot 47
- Enabled fan warning function enable 47
- English 47
- F monitor cpu temperature at 6 47
- F monitor cpu temperature at 7 47
- F monitor cpu temperature at 8 47
- F monitor cpu temperature at 9 47
- If the case is closed case opened will show no if the case have been opened case opened will show yes if you want to reset case opened value set reset case open status to enabled and save cmos your computer will restart 47
- Pc health status 47
- Reset case open status 47
- Adjust agp pci src clock asychrohous with cpu 48
- Agp pci src fixed 48
- Cpu clock ratio 48
- Cpu host clock control 48
- Cpu host frequency mhz 48
- Disabled disable cpu host clock control default value 48
- Enabled enable cpu host clock control 48
- English 48
- For c stepping p4 8x 10x 24x default 15x 48
- For northwood cpu 12x 24x default 16x the option will display locked and read only if the cpu ratio is not changeable 48
- For willamette cpu 8x 23x default 14x 48
- Frequency voltage control 48
- Ga 8i865pe tw motherboard 44 48
- Incorrect using these features may cause your system broken for power end user use only 48
- Mhz 355mhz set cpu host clock from 100mhz to 355mhz if you use a fsb800 pentium 4 processor please set cpu host frequency to 200mhz if you use a fsb533 pentium 4 processor please set cpu host frequency to 133mhz if you use a fsb400 pentium 4 processor please set cpu host frequency to 100mhz 48
- Please note that if your system is overclocked and cannot restart please wait 20secs for automatic system restart or clear the cmos setup data and perform a safe restart 48
- This item will be available when cpu host clock control is set to enabled 48
- This item will be available when cpu host clock control is set to enabled serial ata device is very sensitive to src clock src over clock may make serial ata device function can t work properly 48
- This option will not be shown or not be available if you are using a cpu with the locked ratio this setup option will automatically assign by cpu detection 48
- Agp overvoltage control 49
- Agp pci src frequency mhz 49
- Cpu voltage control 49
- Dimm overvoltage control 49
- English 49
- Memory frequency for 49
- Memory frequency mhz 49
- Normal cpu vcore 49
- English 50
- Fail safe defaults contain the most appropriate values of the system parameters that allow minimum system performance 50
- Ga 8i865pe tw motherboard 46 50
- Load fail safe defaults 50
- Load optimized defaults 50
- Selecting this field loads the factory defaults for bios and chipset features which the system automatically detects 50
- Bios setup 47 51
- English 51
- Set supervisor user password 51
- When you are prompted to enter password a message password disabled will appear to confirm the password being disabled once the password is disabled the system will boot and you can enter setup freely the bios setup program allows you to specify two separate passwords supervisor password and a user password when disabled anyone may access all bios setup program function when enabled the supervisor password is required for entering the bios setup program and having full configuration fields the user password is required to access only basic items if you select system at password check in advance bios features menu you will be prompted for the password every time the system is rebooted or any time you try to enter setup menu if you select setup at password check in advance bios features menu you will be prompted only when you try to enter setup 51
- English 52
- Exit without saving 52
- Ga 8i865pe tw motherboard 48 52
- Save exit setup 52
- Type y will quit the setup utility and save the user setup value to rtc cmos type n will return to setup utility 52
- Type y will quit the setup utility without saving to rtc cmos type n will return to setup utility 52
- Chapter 4 technical reference 53
- English 53
- Gigabyte announces bios 53
- Introduction 53
- Windows bios live update utility 53
- Before you begin 54
- English 54
- Flash bios method introduction 54
- Method 1 q flash 54
- Utility 54
- Before updating 55
- English 55
- Entering the q flash 55
- In the following sections we take ga 8knxp ultra as the example to guide you how to flash bios from an older version to the latest version for example from fa3 to fba 55
- Part one 55
- Some of gigabyte motherboards are equipped with dual bios in the bios menu of the motherboards supporting q flash and dual bios the q flash utility and dual bios utility are combined in the same screen this section only deals with how to use q flash utility 55
- Step 2 press f8 button on your keyboard and then y button to enter the dual bios q flash utility 55
- Step1 to use q flash utility you must press del in the boot screen to enter bios menu 55
- Technical reference 51 55
- The bios file is fa3 55
- Updating bios with q flash 55
- Utility 55
- Utility on dual bios motherboards 55
- Action bar 56
- Dual bios utility screen 56
- English 56
- Exploring the q flash 56
- Task menu for dual bios utility 56
- Task menu for q flash utility 56
- Using the q flash 56
- Utility 56
- After bios file is read you ll see a confirmation dialog box asking you are you sure to update bios 57
- After pressing enter you ll then see the progress of reading the bios file from the floppy disk 57
- Bios file in the floppy disk 57
- Do not trun off power or reset your system at this stage 57
- English 57
- In this example we only download one bios file to the floppy disk so only one bios file 8knxpu fba is listed 57
- Move to the bios file you want to flash and press enter 57
- Please confirm again you have the correct bios file for your motherboard 57
- Please do not take out the floppy disk when it begins flashing bios 57
- Press y button on your keyboard after you are sure to update bios 57
- Technical reference 53 57
- Then it will begin to update bios the progress of updating bios will be displayed 57
- 54 ga 8i865pe tw motherboard 58
- After system reboots you may find the bios version on your boot screen becomes the one you flashed 58
- English 58
- Press any keys to return to the q flash menu when the bios updating procedure is completed 58
- Press esc and then y button to exit the q flash utility the computer will restart automatically after you exit q flash 58
- The bios file becomes fab after updating 58
- You can repeat step 1 to 4 to flash the backup bios too 58
- English 59
- Press del to enter bios menu after system reboots when you are in bios menu move to load fail safe defaults item and press enter to load bios fail safe defaults normally the system redetects all devices after bios has been upgraded therefore we highly recommend reloading the bios defaults after bios has been upgraded 59
- Press enter on your keyboard 59
- Press y on your keyboard to load defaults 59
- Press y on your keyboard to save and exit 59
- Select save exit setup item to save the settings to cmos and exit the bios menu system will reboot after you exit the bios menu the procedure is completed 59
- Technical reference 55 59
- 56 ga 8i865pe tw motherboard 60
- Action bar 60
- Contains the names of four actions needed to operate the q flash utility pressing the buttons mentioned on your keyboards to perform these actions 60
- Contains the names of three tasks blocking a task and pressing enter key on your keyboard to enable execu tion of the task 60
- English 60
- Entering the q flash 60
- Exploring the q flash 60
- Part two 60
- Q flash 60
- Step 2 press f8 button on your keyboard and then y button to enter the q flash utility 60
- Step1 to use the q flash utility you must press del in the boot screen to enter bios menu 60
- Task menu for q flash 60
- Task menu for q flash utility 60
- The q flashbios utility screen consists of the following key components 60
- This part guides users of single bios motherboards how to update bios using the q flas 60
- Updating bios with q flash 60
- Utility 60
- Utility bar 60
- Utility on single bios motherboards 60
- Utility screen 60
- After bios file is read you ll see a confirmation dialog box asking you are you sure to update bios 61
- Bios file in the floppy disk 61
- Do not trun off power or re set your system at this stage 61
- English 61
- If you want to save the current bios for backup purpose you can begin step 1 with save bios to floppy item 61
- In this example we only download one bios file to the floppy disk so only one bios file 8ge800 f4 is listed 61
- Later you will see a box pop up showing the bios files you previously downloaded to the floppy disk 61
- Move to the bios file you want to flash and press enter 61
- Please confirm again you have the correct bios file for your motherboard 61
- Please do not take out the floppy disk when it begins flashing bios 61
- Press arrow buttons on your keyboard to move the light bar to update bios from floppy item in the q flash menu and press enter button 61
- Technical reference 57 61
- This section tells you how to update bios using the q flash utility as described in the before you begin section above you must prepare a floppy disk having the bios file for your motherboard and insert it to your computer if you have already put the floppy disk into your system and have entered the q flash utility please follow the steps below to flash bios 61
- Using the q flash 61
- Utility 61
- 58 ga 8i865pe tw motherboard 62
- After system reboots you may find the bios version on your boot screen becomes the one you flashed 62
- Congratulation you have updated bios successfully 62
- Do not trun off power or re set your system at this stage 62
- English 62
- Press any keys to return to the q flash menu when the bios updating procedure is completed 62
- Press del to enter bios menu after system reboots and load bios fail safe defaults see how to load bios fail safe defaults please kindly refer to step 6 to 7 in part one 62
- Press esc and then y button to exit the q flash utility the computer will restart automatically after you exit q flash 62
- Press y button on your keyboard after you are sure to update bios 62
- The bios file becomes fab after updating 62
- The porcess of updating bios 62
- Then it will begin to update bios the progress of updating bios will be shown at the same time 62
- Click bios item 63
- Click here 63
- Click start programs gigabyte bios 63
- English 63
- Method 2 bio 63
- Methods and steps 63
- Please select bios sever site then click ok 63
- Press here 63
- Utility 63
- English 64
- 4 6 8 channel audio 65
- English 65
- Function introduction 65
- Stereo speakers connection and settings 65
- The installation of windows 98se 2k me xp is very simple please follow next step to install the function 65
- Channel analog audio output mode 66
- English 66
- Channel analog audio output mode 67
- English 67
- Channel audio setup using audio combo kit optional device 68
- English 68
- English 69
- Connecting port 70
- English 70
- Spdif output device optional device 70
- Auto detecting 71
- English 71
- Introduction of audio connectors 71
- Jack sensing and uaj introduction 71
- Jack sensing provides audio connectors error detection function 71
- Enable uaj function 72
- English 72
- Manual setting 72
- Uaj introduction 72
- Boot from cd 73
- English 73
- How to use the xpress recovery 73
- What is xpress recovery 73
- Xpress recovery introduction 73
- 70 ga 8i865pe tw motherboard 74
- English 74
- Execute backup utility 2 execute restore utility 3 remove backup image 4 set password 5 exit and restart 74
- F9 for xpress recovery 74
- If you have already entered xpress recovery by booting from the cd rom you can enter xpress recovery in the future by pressing the f9 key 74
- It is recommended that xpress recovery be immediately installed after os and all required driver and software installations are complete 74
- Press f9 during powering on the computer 74
- Press f9 during powering on the computer text mode 74
- System storage capacity as well as drive reading writing speed will affect backup speed 74
- English 75
- English 76
- Chapter 5 appendix 77
- English 77
- Install chipset driver 77
- Install drivers 77
- Revision history 77
- English 78
- Item description 78
- English 79
- Software application 79
- English 80
- English 81
- English 82
- English 83
- 80 ga 8i865pe tw motherboard 84
- English 84
- If you encounter any trouble during boot up please follow the troubleshooting procedures 84
- Troubleshooting 84
- Appendix 81 85
- English 85
- If the above procedure unable to solve your problem please contact with your local retailer or national distributor for help or you could submit your question to the service mail via gigabyte website technical support zone http www gigabyte com tw the appropriate response will be provided asap 85
- English 86
- Technical support rma sheet 86
- Acronyms 87
- English 87
- English 88
- English 89
- English 90
- English 91
- English 92
- English 93
- English 94
- English 95
- 92 ga 8i865pe tw motherboard 96
- Contact us 96
- Contact us via the information in this page all over the world 96
- English 96
Похожие устройства
- JVC XV-N315B Инструкция по эксплуатации
- Samsung I9300 Galaxy S III 16GB Marble White Инструкция по эксплуатации
- Ballu BSGI-24H Инструкция по эксплуатации
- Gigabyte GA-8I865PE-L Инструкция по эксплуатации
- Rover RoverMedia Aria E10 Инструкция по эксплуатации
- Ballu BSGI-18H Инструкция по эксплуатации
- Gigabyte GA-8I865P-G Инструкция по эксплуатации
- Yamaha PSR-S710 Инструкция по эксплуатации
- Samsung S6802 Galaxy Ace Duos Metallic Black Инструкция по эксплуатации
- Ballu BSGI-12H Инструкция по эксплуатации
- Gigabyte GA-8I865GVME Инструкция по эксплуатации
- Bosch WAA12160BY Инструкция по эксплуатации
- Samsung S6802 Galaxy Ace Duos Chic White Инструкция по эксплуатации
- Ballu BSGI-09H Инструкция по эксплуатации
- Gigabyte GA-8I848E-L Инструкция по эксплуатации
- Bork TV SPR 2140 ** Инструкция по эксплуатации
- Ballu BSCI-12HPC Инструкция по эксплуатации
- Gigabyte GA-8I845PE Pro Инструкция по эксплуатации
- Scarlett SC-982 Инструкция по эксплуатации
- Samsung S5380 Wave Y White Инструкция по эксплуатации
