Gigabyte GA-8I865PE-TW [7/96] English
![Gigabyte GA-8I865PE-TW [7/96] English](/views2/1047434/page7/bg7.png)
Table of Content
English
- 3 -
Load Fail-Safe Defaults .............................................................................. 46
Load Optimized Defaults ............................................................................ 46
Set Supervisor/User Password .................................................................. 47
Save & Exit Setup ...................................................................................... 48
Exit Without Saving .................................................................................... 48
Chapter 4 Technical Reference ............................................................49
@BIOS
TM
Introduction ................................................................................ 49
Flash BIOS Method Introduction ................................................................ 50
2- / 4- / 6- / 8- Channel Audio Function Introduction ................................... 61
Jack-Sensing and UAJ Introduction ........................................................... 67
Xpress Recovery Introduction .................................................................... 69
Chapter 5 Appendix ..............................................................................73
