- 17 - Hardware Installation Process
English
Step 4-2: Connectors Introduction
5
19
7
13
6
13
9
15 14
12
10
11
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) FDD
6) IDE1 / IDE2
7) F_PANEL
8) PWR_LED
9) DIMM_LED
10) F_AUDIO
11) CD_IN
12) SUR_CEN
13) SPDIF_IO
14) F_USB1 / F_USB2
15) COMB
16) IR
17) CI
18) CLR_CMOS
19) BAT
4
18
17
8
2
16
