- 58 -GA-8I845GV Series Motherboard
English
7VRXP F10
AMD-Athlon(tm)Processor-1333MHz
Check System Health !
Checking NVRAM...Update OK
262144KB
DEL:Steup/Dual BIOS/Q-Flash F8:Boot Menu F12:Network boot TAB:Logo
Auto-Detecting Pri Master..IDE Hard Disk
Auto-Detecting Pri Slave...Not Detected
Auto-Detecting Sec Master..ATAPI CDROM
Auto-Detecting Sec Slave.. Not Detected
( C ) American Megatrends Inc.,
62-2003-001199-00101111-040201-KT333-GA7VRXP1-
American Release:08/23/2002
Megatrends AMIBIOS (C) 1999 American Megatrend
The BIOS file is F10
before updating
Entering the Q-Flash
™
utility:
Step1: To use Q-Flash
™
utility, you must press Del in the boot screen to enter BIOS menu.
AMIBIOS SIMPLE SETUP UTILITY - VERSION 2.00
(C) 2001 American Megatrends, Inc. All Rights Reserved
STANDARD CMOS SETUP INTEGRATED PERIPHERALS
BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP
CHIPSET FEATURES SETUP SUPERVISOR PASSWORD
POWER MANAGEMENT SETUP USER PASSWORD
PNP / PCI CONFIGURATION IDE HDD AUTO DETECTION
LOAD FAIL-SAFE DEFAULTS SAVE & EXIT SETUP
LOAD OPTIMIZED DEFAULTS EXIT WITHOUT SAVING
ESC: Quit : Select Item F5: Old Values F6: Fail-Safe Values
F7: Optimized Values F8: Dual BIOS/Q-Flash F10:Save & Exit
Load Fail-Safe Defaults
Part One:
Updating BIOS with Q-Flash
™
Utility on Dual BIOS Motherboards.
Some of Gigabyte motherboards are equipped with dual BIOS. In the BIOS menu of the motherboards
supporting Q-Flash
™
and Dual BIOS, the Q-Flash
™
utility and Dual BIOS utility are combined in the
same screen. This section only deals with how to use Q-Flash
™
utility.
In the following sections, we take GA-7VRXP as the example to guide you how to flash BIOS
from an older version to the latest version. For example, from F10 to F12.
