- 35 - BIOS Setup

2-7 PnP/PCI Configurations

PCI1 IRQ Assignment

Auto BIOS auto-assigns IRQ to the first PCI slot. (Default)

3,4,5,7,9,10,11,12,14,15 Assigns IRQ 3,4,5,7,9,10,11,12,14,15 to the first PCI slot.

KLJI
