Hardware Installation- 27 -
English
1
Pin No. Definition
1 MPD+
2 MPD-
3 MPD-
18) PWR_LED
PWR_LED is connect with the system power indicator to indicate whether the system is on/off. It
will blink when the system enters suspend mode.
