GA-8I865GM(F)K-775 Motherboard - 48 -
English
3-2 Software Application
This page displays all the tools that Gigabyte developed and some free software, you can choose anyone
you want and press "install" to install them.
3-3 Software Information
This page lists the contents of software and drivers in this CD-title.
