ID Card Printer – User Manual
ID Card Printer – User Manual
- 11 -
USING YOUR ID CARD PRINTER
Printer parts
1. Lid
opening latch
2. Thermal print head
3. Card cleaning roller
4. LCD display screen
5. Soft function buttons
6. Hand feed/cleaning card entry
7. 30 card capacity stacker
8. 100 card capacity hopper
9. USB port
10. DC power input
