9 Operation range
OPERATING RANGE
Operating Limits:
Thermal carrier : Water
Water temperature : 5 ~65°C
Maximum water pressure : 16 bar
Air temperature : (as below)
Cooling Mode
Minimum indoor
16.0 / 60.8 11.0 / 51.8
temperature
Maximum indoor
32.0 / 89.6 23.0 / 73.4
temperature
Minimum outdoor
16.0 / 60.8 -
temperature
Maximum outdoor
46.0 / 114.8 -
temperature
Heating Mode
Ts: Dry bulb temperature. Th: Wet bulb temperature.
Temperature Ts °C/°F Th °C/°FTemperature Ts °C/°F Th °C/°F
Minimum indoor
16.0 / 60.8 -
temperature
Maximum indoor
30.0 / 86.0 -
temperature
Minimum outdoor
-5.0 / 23.0 -6.0 / 21.2
temperature
Maximum outdoor
24.0 / 75.2 18.0 / 64.4
temperature
FWC-F
OPERATING RANGE
Operating Limits:
Thermal carrier : Water
Water temperature : 5 ~50°C
Maximum water pressure : 16 bar
Air temperature : (as below)
Cooling Mode
F°/C°hTF°/C°sTerutarepmeT
Minimum indoor temperature 16.0 / 60.8 11.0 / 51.8
Maximum indoor temperature 32.0 / 89.6 23.0 / 73.4
Minimum outdoor temperature 16.0 / 60.8 -
Maximum outdoor temperature 46.0 / 114.8 -
Heating Mode
Ts: Dry bulb temperature. Th: Wet bulb temperature.
F°/C°hTF°/C°sTerutarepmeT
Minimum indoor temperature 16.0 / 60.8 -
Maximum indoor temperature 30.0 / 86.0 -
Minimum outdoor temperature -5.0 / 23.0 -6.0 / 21.2
Maximum outdoor temperature 24.0 / 75.2 18.0 / 64.4
