Daikin FWC05AF [9/26] Specifications

• Fan coil units • Ceiling mounted cassette unit • FWC

2 Specifications

Standard heat

exchanger

Rows mm 2 2

Stages mm 4 4

Fin pitch mm 1.59 1.59

Face area m² 0.47 0.47

Water volume l 2.69 2.69

Air filter Washable Sarannet

Insulation material PE

Vibration insulation Rubber Bush (Fan Motor)

Water

connections

Std. heat exchanger inch 3/4’’

Drain mm 19.05 19.05

Notes Rating conditions cooling 2 pipe: air 27

Rating conditions heating 2 pipe : air 20

Sound power level according to ISO3741

Sound pressure measured at 1 m in front of the unit and 0.8 m below the vertical centre line of the unit. (JIS C 9612)

Sound pressure measured at 1,4m below the facia (JIS C 9612)

Sound pressure measured at 1,5m below the facia (JIS B 8615)

Rating conditions heating 4 pipe : air 20

2-3 ELECTRICAL SPECIFICATIONS FWC02AF FWC03AF FWC04AF FWC05AF FWC06AF FWC07AT FWC08AT FWC10AT

Current input High A 0.53 0.61 0.67 0.80 1.02 0.52 0.64 0.68

Medium A 0.48 0.49 0.57 0.65 0.84 0.47 0.51 0.58

Low A 0.43 0.43 0.50 0.51 0.74 0.42 0.45 0.51

Required power supply V / f /

220-240 / 1 / 50

Required fuses A 22222222

Required wire section mm² 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5

2-3 ELECTRICAL SPECIFICATIONS FWC11AT FWC12AT

Current input High A 0.79 1.06

Medium A 0.64 0.87

Low A 0.50 0.78

Required power supply V / f /

220-240 / 1 / 50

Required fuses A 2 2

Required wire section mm² 1.5 1.5

2-2 TECHNICAL SPECIFICATIONS FWC11AT FWC12AT
