Crate V3112T [10/12] V3112 guitar amplifier
![Crate V3112T [10/12] V3112 guitar amplifier](/views2/1004895/page10/bga.png)
10
V3112 Guitar Amplifier
System Block Diagram:
GUITAR
INPUT
OVERDRIVE
GAIN
REVERB
LEVEL
REVERB
DRIVE
8 OHM
SPEAKER
EFFECTS
SEND
EFFECTS
RETURN
REVERB
RECOVERY
CLEAN
VOLUME
OVERDRIVE
LEVEL
CHANNEL
SELECT
12AX7A
V1A
12AX7A
V1B
12AX7A
V2A
12AX7A
V2B
CHANNEL
SELECT
PHASE
SPLITTER
EL84
V4
EL84
V5
EL84
V6
EL84
V7
12AX7A
V3A
12AX7A
V3B
BASSTREBLE MID
BOOST PRESENCE
