Assembly

Inserting/Replacing the Batteries

Alkali-manganese batteries are recommended for the measuring tool.

To open the battery lid 4, press on the latch 3 and fold the battery lid up.

Insert the batteries. When inserting, pay attention to the correct polarity

according to the representation on the inside of the battery lid.

Always replace all batteries at the same time. Only use batteries from one

brand and with the identical capacity.

 Remove the batteries from the measuring tool when not using it

for extended periods. When storing for extended periods, the

batteries can corrode and self-discharge.

Operation

Initial Operation

 Protect the measuring tool against moisture and direct sun light.

 Do not subject the measuring tool to extreme temperatures or

variations in temperature. As an example, do not leave it in vehicles

for a long time. In case of large variations in temperature, allow the

measuring tool to adjust to the ambient temperature before putting it

into operation. In case of extreme temperatures or variations in

temperature, the accuracy of the measuring tool can be impaired.

 Avoid heavy impact or falling of the measuring tool. After heavy ex-

terior impact on the measuring tool, an accuracy check should always

be carried out before continuing to work (see “Levelling Accuracy”).

 Push the switch for automatic levelling 2 to the position when

transporting the measuring tool. This locks the levelling unit, which

can be damaged in case of intense movement.

Switching On and Off

To switch on the measuring tool, press the On/Off button 5. Immediately

after switching on, the measuring tool sends a laser beams out of the exit

opening 1.

 Do not point the laser beam at persons or animals and do not look

into the laser beam yourself, not even from a large distance.
