2 TS5000A User Manual

1. Model and specification

1.1. Model number

TS5000A: Motorized Tripod Turnstile

TS5011A: Motorized Tripod Turnstile with Controller and RFID Reader

TS5022A: Motorized Tripod Turnstile with Controller and Fingerprint Reader with RFID function.

As shown below:

Access

Model

C3-200 with two

RFID reader

inBIO260 with two FP

reader

S5000A

√

S5011A

√

S5022A

√

Table 1-1

Please read this document carefully before installation and using the device.

1.2. Technical specifications

Input Voltage

AC 100V ~ 240V,

50Hz ~ 60Hz

Max Tolerance of Arms

Center: 80 kg

End: 40 kg

Rated Power 60 W Drive Mode Motorized

Operating Environment

Indoor and Outdoor

(shelter)

Arm Length (mm) 500

Operating Temperature -28ºC ~ 60ºC Net Weight（kg） 60

Operating Humidity 5% ~ 80% Gross Weight（kg） 90

Flow Rate 30 passages / minute Dimension(mm)

L = 1200, W = 300, H =

1010

Input Control Signal Dry contact Package Size (mm)

L =1330 , W =420 , H

=1110

Table 1-2

TS5000A’s appearance and dimensions are as shown in figure 1-1：

Figure 1–1
