2. OPERATING INSTRUCTIONS

2.1 Initial Checks

Check for any transit damage.

2.2 Needles and Thread

The thread recommended is either glazed cotton or ethylene,although other steps can be used.

Recommendations:

TABLE 1

MACHINE TYPE NEEDLE SIZE THREAD SIZE RPM

6003-1 DP×5 135×5 18/110 120-200 0-2500

6003-2 DP×5 135×5 22/140 100-120 0-2500

2.3 Threading up

Fit the needle to the needle bar,short groove (or scarf) uppermost,and make sure it is fully back

against its stop.

Thread up following the diagram opposite.

1) Threading the Machine

See Fig.1, take thread through thread guide stud No.1-1 of first hole, then through thread tension

guide no.1-2 of second hole, forward and over between the thread guide no.1-4, then go through

clasp No.1-5, make the thread in and between the screw No. 1-6, down and through the groove until

the right side of needle bar, then forward through the hole of thread tension guide No. 1-7. Finally,

from the underside, pass the thread up through the needle eye.（Seeing Fig 3）

Picture 3

2.4 Thread Tension

To decrease thread tension, turn the tension nut counter clockwise（1-8）;

To increase thread tension, turn the tension nut clockwise（1-8）.

2.5 Maintenance

Always check that the pump is pumping oil into the sight dome.If it is not,the most likely

causes are either a blocked filter,or insufficient oil-check the oil level gauge.The oil should be

completely changed at YEARLY INTERVALS. To do this, remove the machine from the base,tip the

dirty oil away,and clean the tray and the filter on the pump. Replace the machine on its base.

Remove the machine lid and fill with 2 bottles of 800ml oil. If the needle or looper are bent,change

them immediately.
