8.CS-7500-BT（CS-7500-5BT）

针送料机构

NEEDLE FEED MECHANISM

零件号码零件名称件数备注零件号码零件名称件数备注

Parts No. Name of Parts

QTY Parts No. QTY Remarks

BNBK091310 滚针轴承----------

-

Roller Bearing------------------------- 1 ZSL15002 螺帽----------------

-

N

ut(15/64-28)-------------------

-

1

FD1072-0A 针杆摆动轴-------

-

N

eedle Rod Rocking Base Shaft---

-

1 ZSL15004 螺帽----------------

-

N

ut(15/64-28)-------------------

-

1

FD1073-0B 针杆摆动架-------

-

Bracket---------------------------------

-

1

FD1081-0A 摆动导轨----------

-

Slide Block Guide--------------------

-

1

FD1340-0A 针送料轴----------

-

Connecting Shaft---------------------

-

1

FD1341-0A 前轴套-------------

-

Rock Shaft Bushing Front-----------

-

1

FD1342-0A 固定环-------------

-

Thrust Collar Asm--------------------

-

2

FD1343-0A 后轴套-------------

-

Rock Shaft Bushing Rear------------ 1

FD1345-0A 前曲柄-------------

-

Driving Crank Front------------------ 1

FD1346-0A 驱动杆-------------

-

Driving Link--------------------------- 1

FD1347-0A 驱动销-------------

-

N

eedle Bar Link Pin------------------ 2

FD1348-0A 后曲柄-------------

-

Shaft Arm Asm (Rear)---------------

-

1

FD1349-0A 连接杆-------------

-

Connecting Rod----------------------- 1

FD1350-0A 连接杆销----------

-

Connecting Rod Shaft---------------- 1

FD1352-0A 摆动架导向块----

-

N

eedle Bar Frame Guide------------

-

1

FD1353-0A 摆动架轴套-------

-

Bushing--------------------------------

-

1

OAGM071103 油封----------

Belt-------------------------------------

-

1

RC100105 卡簧----------

Spring----------------------------------

-

1

WA069001 垫圈----------------

-

Washer---------------------------------

-

1

ZSA11025 螺丝----------------

-

Screw (11/64-40×2.7)----------------

-

1

ZSA12010 螺丝----------------

-

Screw (3/16-28×7)-------------------- 2

ZSA16012 螺丝----------------

-

Screw (1/4-40×4)---------------------

-

4

ZSB09007 螺丝----------------

-

Screw (9/64-40×7.5)-----------------

-

2

ZSB09090 螺丝----------------

-

Screw (9/64-40×3.8)-----------------

-

2

ZSB11069 螺丝----------------

-

Screw (11/64-40×5)------------------

-

1

ZSB12002 螺丝----------------

-

Screw (3/16-28×12)------------------

-

1

ZSB12012 螺丝----------------

-

Screw (3/16-28×15)------------------

-

1

ZSB12063 螺丝----------------

-

Screw (3/16-28×14)------------------

-

1

ZSG15085 螺丝----------------

-

Screw (15/64-28×7.5)----------------

-

1

Remarks

Name of Parts

17
