零件号码 零件名称 件数 备注 零件号码 零件名称 件数 备注
Parts No. Name of Parts
QTY Parts No. QTY Remarks
5100132000 竖轴----------------
-
Upright Shaft--------------------------
-
1 ZSB11008 螺丝----------------
-
Screw (11/64-40×5)------------
-
2
5100132100 竖轴上套----------
-
Upright Shaft Bushing Upper-------
-
1 ZSB11026 螺丝----------------
-
Screw (11/64-40×10)-----------
-
1
5100132200 竖轴下套----------
-
Upright Shaft Bushing Lower------- 1 ZSB12053 螺丝----------------
-
Screw (3/16-28×9)--------------
-
1
5100133000 上轴伞齿轮-------
-
Gear Asm------------------------------
-
1
5100133100 竖轴上伞齿轮----
-
Pinion Asm----------------------------
-
1
5100140800 针棒线挂----------
-
N
eedle Thread Guide----------------
-
1
5100140900 针棒钳-------------
N
eedle Bar Connecting Asm-------- 1
5100180100 下轴----------------
-
Hook Driving Shaft------------------
-
1
5100180300 下轴前套----------
-
Hook Driving Shaft Bush------------ 1
5100180500 下轴后套----------
-
Bushing, Rear-------------------------
-
1
5100180600 竖轴下伞齿轮----
-
Gear Asm------------------------------
-
1
5100180700 下轴伞齿轮-------
-
Pinion Asm----------------------------
-
1
5100183200 梭芯----------------
-
Bobbin---------------------------------
-
1
5100184900 固定环-------------
Thrust Collar Asm--------------------
-
1
5100188200 挡油圈-------------
Thrust Collar Asm--------------------
-
1
5100354400 下轴限油螺丝----
-
Oil Seal Screw------------------------
-
1
5100354500 油芯----------------
-
Oil Wick-------------------------------
-
1
SC82-J 梭壳----------------
-
Bobbin Case Asm--------------------
-
1
KHS12-GTHD-T 旋梭----------------
-
Hook Asm-----------------------------
-
1
51001858T0 牛角----------------
-
Bobbin Case Positioning Finger----
-
1
FD1070-0A 针棒----------------
-
N
eedle Bar----------------------------- 1
FD1077-0A 针棒油盖----------
-
Rubber Plug---------------------------
-
1
FD1082-0A 导引滑块----------
-
Slide Block----------------------------
-
1
INDB*1#11 针-------------------
-
N
eedle----------------------------------
-
1
INDB*1#14 针-------------------
-
N
eedle----------------------------------
-
1 CS-7500-5BT
ZSA11004 螺丝----------------
-
Screw (11/64-40×3.5)----------------
-
2
ZSA15016 螺丝----------------
-
Screw (15/64-28×7)------------------
-
2
ZSA16022 螺丝----------------
-
Screw (1/4-40×7)---------------------
-
8
ZSB08010 螺丝----------------
-
Screw (1/8-44×4.6)-------------------
-
1
ZSB09014 螺丝----------------
-
Screw (9/64-40×6)-------------------- 1
3.CS-7500-BT（CS-7500-5BT） 针棒竖轴下轴机构 NEEDLE BAR UPRIGHT SHAFT LOWER SHAFT MECHANISM
Remarks
Name of Parts
7
