零件号码 零件名称 件数 备注 零件号码 零件名称 件数 备注
Parts No. Name of Parts
QTY Parts No. QTY Remarks
5100120100 上轴----------------
-
Main Shaft-----------------------------
-
1 WA049003 垫圈----------------
-
Washer---------------------------- 2
5100120500 后套油盖组件----
-
Oil Seal--------------------------------- 1 XB106001 油棉----------------
-
Roller Felt------------------------
-
1
5100120800 凸轮曲柄----------
-
Counter Weight-----------------------
-
1 ZME05001 螺丝----------------
-
Screw (M5-0.8×9.3)------------
-
2
5100121000 针棒连接杆-------
-
N
eedle Bar Crank Rod---------------
-
1 ZSA15010 螺丝----------------
-
Screw (15/64-28×13)-----------
-
2
5100121300 针棒连接轴-------
-
N
eedle Bar Crank--------------------- 1 ZSA15037 螺丝----------------
-
Screw (15/64-28×8.5)----------
-
1
5100122100 偏心轮盖板-------
-
Thrust Collar--------------------------
-
1 ZSA16025 螺丝----------------
-
Screw (1/4-40×6)---------------
-
4
5100122600 固定环-------------
Thrust Collar Asm--------------------
-
1 ZSA18002 螺丝----------------
-
Screw (9/32-28×11.5)----------
-
1
5100190105 天秤组件----------
-
Thread Take-up Complete----------- 1 ZSB09014 螺丝----------------
-
Screw (9/64-40×6)--------------
-
2
5100190500 挡油环-------------
Rubber---------------------------------
-
1 ZSB11076 螺丝----------------
-
Screw (11/64-40×12)-----------
-
2
5100192000 天秤架-------------
Lever-----------------------------------
-
1 ZSB16031 螺丝----------------
-
Screw (1/4-40×11)--------------
-
2
5100192200 销油线-------------
Oil Thread-----------------------------
-
1 ZSB18011 螺丝----------------
-
Screw (9/32-28×11)------------
-
1
5100354200 油量调节销-------
-
Oil Amount Adjusting Pin----------- 1 ZSK09005 螺丝----------------
-
Screw (9/64-40×6)--------------
-
1
5100354300 调节销圈----------
-
Oil Adjusting Collar------------------ 1
51006020T5 定位磁盘组件----
-
Dynamo Stator------------------------
-
1
51001204T0 上轴后套----------
-
Main Shaft Bushing,Rear------------ 1
51001223T5 上轮组件----------
-
Flywheel Asm------------------------- 1
51006024T5 磁铁台(A)---------
Magnet Fitting Base A Asm--------
-
1
51006024T6 磁铁台(B)---------
Magnet Fitting Base B Asm--------- 1
51006027T0 磁铁(C)------------
-
Magnet C------------------------------
-
1
51001220H4 偏心轮-------------
Feed Drive Eccentric Cam----------
-
1 CS-7500-5BT
BN081208 滚针轴承----------
-
Roller Bearing------------------------- 2
FD1061-0A 天秤固定销-------
-
Thread Take-up Crank Shaft Asm------
-
1
FD1101-0A 上轴前套----------
-
Front Bushing ------------------------
-
1
FD1102-0A 上轴中套----------
-
Intermediate Bushing ---------------- 1
FD1103-0A 中套接头----------
-
Joint------------------------------------
-
1
FD1116-0A 偏心轮-------------
Feed Drive Eccentric Cam----------
-
1
OPP0029178 O型圈--------------
-
Rubber Ring---------------------------
-
1
OPP0044240 定位O型圈--------
-
Rubber Ring---------------------------
-
1
RB200200 挡圈----------------
-
Snap Ring------------------------------ 1
RU010100 扎带----------------
-
Clip-------------------------------------
-
1
2.CS-7500-BT（CS-7500-5BT） 上轴挑线机构 MAIN SHAFT THREAD TAKE-UP LEVER MECHANISM
Remarks
Name of Parts
5
