Earth/Ground Tester
Accessories
5
Models and Accessories
Table 2 lists the models and accessories.
Table 2. Models and Accessories
Description Item/Part Number
Earth Ground Tester - Basic
(Includes manual, 2 leads and 2 clips)
Fluke-1623
Earth Ground Tester - Fully Loaded
(Includes manual, 2 leads and 2 clips,
ES162P4, EI-1623)
Fluke-1623 Kit
Service Replacement Kit
(Includes 2 Leads, 2 Clips)
Fluke-162x-7001
Stake Set for 3 Pole Measurement
(Includes three stakes, one 25 m cable
reel, one 50 m cable reel)
ES-162P3
Stake set for 4 Pole Measurement
(Includes four stakes, two 25 m cable
reels, one 50 m cable reel)
ES-162P4
Selective/Stakeless Clamp Set for
1623, Consists oF EI-162X and EI-
162AC
EI-1623
Clip-on Current Transformer (sensing)
with shielded cable set
EI-162X
Shielded Cable (Used w/EI-162X
Clamp)
2630254
Clip-on Current Transformer (inducing) EI-162AC
12.7 Inch (320mm) Spilt Core
Transformer
EI-162BN
Earth Stake 2630222
Cable Reel w/25m Wire 2630231
Cable Reel w/50m Wire 2630246
1623 Users Manual 2560327
