WHEELS AND AXLES

Model 921012, 013, 020,

Item Part No. Qty. Description

1 07100227 1 Tire/Wheel, RH 15 x 5.00-6 Remote

07100228 1 Tire/Wheel, LH 15 x 5.00-6 Remote

07100726 AR Tire, 15 x 5.00-6 K478

2 05700001 2 Clip, Snap

3 06436300 4 Washer, Flat Steel 1.010 x 1.505 x .062

4 00275100 2 Bushing, Rake Shaft 1"

5 07400034 6 Screw, Tapping Hex Washer Head .25-20 x .50

6 05500122 1 Bushing, Sleeve

7 06601200 1 Woodruff Key .25 x .750 x .313 SAE 91

8 00371000 1 Gear, Spur

9 00865600 1 Axle, Long Clicker

10 00865700 1 Axle, Short Clicker

11 00427700 1 Spring, Compression

12 05800300 2 Pin-Roll .188 x 1.25

13 06600002 2 Key, Rectangular .25 x .188 x 1.00

14 00386900 2 Clutch, Dog Sliding

15 00391100 2 Bushing, Flange

16 00387100 1 Gear, Clutch

17 00387000 1 Gear, Ratchet

18 05500030 2 Bushing, Flange Split Nyliner 1.0" HP

19 08300023 1 Spring, Extension

20 05500023 2 Bushing, Sleeve Bronze

21 52101100 AR Axle, Clicker With Bushings (Includes 10 and 20)

22 06400332 1 Washer, Flat-Steel 1.010 x 1.250 x .068

23 05900602 1 Bolt, Shoulder .50 x 1.50 .38-16 x .625

24 06542000 1 Nut, Locking-Top-Flange .38-16

PS0791
