Ariens ST28 DELUXE TRACK [17/33] Rack an

TRACK AND AXLES

Model 921014, 015, 016, 311, 312

Item Part No. Qty. Description

1 00669700 2 Track, Rubber

2 00670351 2 Wheel, Drive-Track

3 06543500 18 Nut, Locking-Top-Flange .25-20

4 05700001 2 Clip, Snap

5 03293600 4 Wheel, Bogie - Single Bearing

6 06219900 6 Bolt, Round Head Square Neck .25-20 x .75 Grade 5

7 03275800 1 Axle, Front

8 05946800 12 Bolt, Hex .25-20 x .75 Grade 5

9 06436300 2 Washer, Flat-Steel 1.010 x 1.505 x .062

10 03375751 1 Side Plate, Right Hand-Track

11 07000040 2 Bolt, Eye

12 03293700 1 Axle, Rear

13 06543100 8 Nut, Locking-Top-Flange .31-18

14 01305900 1 Flange Bushing

15 05946900 1 Bolt, Hex .31-18 x 1.00 Grade 5

16 03291500 1 Axle, Track

17 00371000 1 Gear, Spur

18 06530300 4 Nut, Locking-Nylon .625-18

19 00660751 2 Runner, Guide-Track

20 06215700 4 Bolt, Round Head Square Neck .31-18 x .75 Grade 5

21 06534800 2 Nut, Locking Flange Gr. A .375-16

PS0820
