en quantities of food up to 2 kg can be frozen without fast freeze To switch ON fast freeze simply press the fast freeze button Figure 0 8 The yellow pilot light indicates that fast freeze is ON The refrigerating unit now operates continuously The freezer compartment drops to a low temperature After inserting fresh produce into the freezer compartment switch OFF fast freezing The freezing process is now controlled automatically by the appliance at a reduced power consumption When the temperature indicator Fig 0 is in the black area the freezing process is complete Effective capacity Specifications on the effective capacity without interior features according to the current standard can be found on the rating plate With interior features the usable capacity according to the rating plate specifications is Freezer compartment Effective Usable capacity capacity 1001 801 Storing food Always ensure that all the freezer drawers have been pushed in all the way otherwise the air will not circulate properly in the appliance If a lot of food is to be stored all the freezer drawers except the bottom one can be taken out of the appliance and the food stacked directly on the freezer grids 22 To remove the freezer drawers pull out all the way lift at the front and remove Fig Q The space under the bottom drawer Fig 0 can also be used for storing flat frozen food To prevent rapid warming of the food in the event of a power failure or a fault place ice blocks directly on the food in the top compartment Freezer calendar Fig 0 not all models The figures next to the symbols indicate the permitted storage period in months of the produce If frozen produce is purchased comply with the manufacturer s date or sell by date Ice block Fig H A not all models if enclosed quantity may vary If a power failure or malfunction occurs the ice blocks can be used to slow down the thawing process The ice blocks can also be used to cool food temporarily e g in a cold bag Making ice Fig 0 Fill the ice tray three quarters full with water and place in the bottom of the freezer compartment If the ice tray is stuck to the freezer compartment loosen with a spoon handle etc Do NOT use pointed or sharp edged implements To facilitate removing the ice cubes twist the ice tray slightly or hold briefly under flowing water
