Samsung DSR 9500A [32/38] Channel organising

DSR 9500A FTA, CI, EM VIA, VIA CI

2. Channel Organising

The "Channel Organising" menu has seven

functions:

The "Channel Organising" menu is used to delete

the Satellites, Transponders and Channels or to make

Favorite channels or move channel as you want.

● Enter the PIN code.

If you have not entered your own PIN code PIN code

0000 applies, which was set at the factory.

2.1 Delete Satellite

● Select the desired satellite list you want to delete

by pressing Red ( ) key.

● Press key for confirmation.

NNoottee

: This feature doesn’t delete satellite itself

but deletes the list of channels registered

for satellite.

2.2 Delete Transponder

● Select the desired transponder list you want to

delete by pressing Red ( ) key.

● Press key for confirmation.

NNoottee

: This feature doesn’t delete transponder itself

but deletes the list of channels registered for

transponder.

● Select the FEC(Forward Error Correction)of the transponder

you want to find.

You can select the value of 1/2, 2/3, 3/4, 5/6, 7/8 or Auto.

● Select the polarization of the transponder you want to find.

(Horizontal/Vertical/Circular Left/Circular Right)

In the case of horizontal, 18V and in the case of vertical,

13V are output through LNB line.

● Select Scan Mode “All” or “Only Free”.

● Select Network Search “Yes”.

You can find more transponders using the home network.

● Select PID searching “Yes”. You can manually search by entering individual

PID(Packet Identifier)(Video/Audio/PCR) values.

● After select option, press key to start the scan process.

1.6 SMATV Scanning

In case that several generations use Antenna and LNB

in common, search the service the from 950 to 2150MHz.

● Select Searching Type “Automatic” or “Manual”.

● Select Scan Mode “All” or “Only Free”.

● You can input alternative symbol rate from 1 to 4

NNoottee

: 1. When your searching type is set to Automatic

during SMATV scanning, you have only to enter

the alternative symbol rate(1~4) you want.

2. When your searching type is set to Manual

during SMATV scanning, you must enter both

frequency and symbol rate.

1.7 Reset to Factory Defaults

This to restore the factory set values in case the user

has encountered some problems after changing any

values of channel data and others which may be in error.

The screen display will be as follows:

At the request window,

if you press key, the receiver will be reset to factory

default settings automatically.

NNoottee

: This cause your previous settings to be deleted!

OPERATING THE RECEIVEROPERATING THE RECEIVER

GB-20

DIGITAL SATELLITE RECEIVER

GB-21

DSR 9500A_GB 12/8/03 1:04 PM Page 20
