Operation CoolAir SP950

6.2 Control panel

The following control and display elements are available on the control panel for

operating the system:

No. in

fig. 2, page 3

Meaning

button

2 Fault LED (red)

The LED indicates system malfunctions.

3 Compressor LED (yellow)

The LED lights up when the compressor is operating.

button

Use the button to switch between operating modes 1, 2, 3 or

Automatic and the Timer function.

5 Digital display

Shows:

• the selected operating mode

for operating mode 1

for operating mode 2

for operating mode 3

A for automatic mode

000 for the timer function

• Selected temperature in °C (target)

6 + button

The + button increases the temperature by 1 °C or the timer running

time by 10 minutes.

7 – button

The – button decreases the temperature by 1 °C or the timer running

time by 10 minutes.

8 POWER LED (blue)

The LED indicates that the system is switched on.

9 Infrared receiver (for the remote control)
