20
To remove the fold back hard floor adapter from the carpet spraying
nozzle, push the slide upwards and then press the red nozzle lock
towards the inside. Release the hard floor adapter from its hinge and
remove.
Proceed in the reverse order to fit the wipe adapter.
The microfibre pad is to be run over the strip so that the nozzle suction
channel is open or remains open.
Set the water volume control-
ler (25) to “min”. Start spraying
operation for 2–3 seconds and
moisturise microfibre pad (white).
Wetting the surface has to be
avoided because under these cir-
cumstances wetting of edge area
of parquet or floor elements is
not adequately protected against
moisture.
Window cleaning
Fit the wipe adapter to the carpet spray nozzle. To assemble see
maintenance cleaning instructions for smooth floors.
The microfibre pad for window cleaning (grey) is to be connected to
the wiper.
You can clean and dry your windows and glass surfaces at the same
time by this method.
Procedure see carpet cleaning
Upholstery cleaning
Use the upholstery spraying nozzle to clean upholstered furniture, car
seats, etc. Push this nozzle on the grip. Connect the spraying hose to
the shut-off valve.
When cleaning upholstery make sure that not too much liquid is
applied because you will have to take a longer drying time into
account depending on the floor underneath.
Flow rate control on the hand grip.
See carpet cleaning for procedure.
We recommend THOMAS ProTex cleaning agent for uphols-
tery cleaning.
Cleaning and care
Only service and clean the appliance when it is switched off and
the mains power plug has been disconnected from the mains power
supply.
After dry vacuuming
– The hygiene box can, if needed, be cleaned.
For this, take out the HEPA bag and dismantle the activated car-
bon filter.
The inside of the hygiene box can now be cleaned with a damp
cloth. If it is very dirty, it can be cleaned in the dishwasher.
Allow the hygiene box to completely dry before putting back the
complete filter.
Replacement interval for the activated carbon filter: every 12
months, replace the HEPA bag if required.
After wash cleaning
Please use a moist soft cloth to clean the appliance housing.
Do not use any aggressive cleaning detergent or solvents.
Remove fresh water tank and empty.
Empty waste water tank.
Clean anti-swash insert, waste water tank and wet filter using
clear, possibly warm water.
Check motor protection filter for contamination and clean
under flowing water and renew, if necessary.
Keep float (13b) in the waste water tank clean and fully
functional at all times. This float interrupts the suction operation
if the waste water tank is full.
Dry up spray water in suction chamber with soft cloth.
Remove contamination on the intake connector and on the
inside of the housing cover.
The housing cover can be taken off the appliance
for easier cleaning.
To do this open the cover and swing down vertically. Press the
cover forwards until it slides out of the hinge. Afterwards swing
the cover upwards and out of the way.
Insert in the housing cover vertically and close it to fasten. The
cover automatically clicks into the hinge.
Fill the fresh water tank with clear water to service
the pump and valves and to make the appliance
ready for operation.
Put the spraying system into operation (operate
the lever on the shut-off valve) over a wash basin,
for example.
The appliance and accessory parts are to be thoroughly dried
after being used for cleaning.
Press the shut-off valve lever to make the system completely
pressureless.
MKA microfilter
The MKA microfilter (19) is to be replaced every six months.
To do this press down the two plastic lugs on the blow-out cover and
fold it back.
Replace the MKA microfilter. Close the blow-out cover again.
Further supplies / special accessories
An extensive range of special accessories and further supplies are
available for your THOMAS HYGIENE T2.
Get further details by returning the accompanying reply card to us or
get further information from your specialist dealer or directly from the
THOMAS Customer Service Department.
Note!
You can only assure a properly functioning appliance and efficient
cleaning by using original THOMAS accessories.
800 ml
max.
250 ml
min.
